CENTRIC part description
Product Description
Centric Premium Brake Drum
Features & Benefits
- OE style castings ensure superior performance and extended service life. Machined finishes provide cleaner appearance through wheels. Precision machined friction surfaces ensure smooth operation and reduced noise
Product Attributes
| Weight [cntrc] Kgs | 11.136 |
| Weight [cntrc] Lbs | 24.500 |
| Mounting Type [cntrc] | Floating |
| Bolt Circle Diameter [cntrc] Mm | 139.700 |
| Bolt Circle Diameter [cntrc] In | 5.500 |
| Hub Hole / Register [cntrc] Mm | 78.486 |
| Hub Hole / Register [cntrc] In | 3.090 |
| Height [cntrc] Mm | 104.394 |
| Height [cntrc] In | 4.110 |
| Friction Surface Width [cntrc] Mm | 74.676 |
| Friction Surface Width [cntrc] In | 2.940 |
| Product Grade [cntrc] | Premium |
| Maximum Brake Diameter (Discard) | 282.300 MM |
| Maximum Brake Diameter (Discard) | 11.114 IN |
| Bolt Hole Quantity | 5 |
| Outside Diameter | 326.898 MM |
| Outside Diameter | 12.870 IN |
| Outer Cooling Fins | No |
| Mounting Hole Diameter | 17.020 MM |
| Mounting Hole Diameter | 0.670 IN |
| Nominal Drum Diameter | 280.000 MM |
| Nominal Drum Diameter | 11.020 IN |
Additional Information
| Harmonized Tariff Code (HTS) | 8708305030 |
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 805890022077 |
Part Interchanges
CENTRIC 122.67038 Cross Reference
We have 4 alternatives for the 122.67038 by CENTRIC:
Fits Vehicles
- Dodge Ramcharger (2000-2001)
- Dodge Ram 1500 (2000-2001)
