CENTRIC part description

Technical Specifications:

Series C-Tek Series
Solid Or Vented Type Rotor Solid
Outside Diameter 11.18 in.
Discard Thickness 0.44 in.
Nominal Thickness 0.50 in.
Hub Hole/Whl Reg mm 79.1
Mounting Type Behind the Hub
UPC 805890305156
Harmonized Tariff Code 8708305030

Application Summary:

  • 1968 - 1970 American Motors AMX
  • 1970 - 1970 American Motors Hornet
  • 1968 - 1970 American Motors Javelin
  • 1969 - 1969 American Motors Rambler
  • 1967 - 1970 American Motors Rebel

Centric® C-Tek™ Standard Disc Brake Rotor

Drive confidently knowing that you have a Centric® C-Tek™ standard disc brake rotor that ensures smoother and quieter stops. Engineered to original equipment specifications and using OE production processes, this brake rotor is an ideal choice for daily commuters looking for a straightforward replacement for their worn-out rotor.

Features & Benefits
  • Crafted using premium-quality G11H18 metallurgy for superior braking power and durability
  • Built and tested by experts to meet QS and ISO Quality System Standards
  • Centric’s machining processes ensure smooth braking for a more confident brake application
  • Double disc grinding prevents run out and guarantees parallelism for ideal disc thickness variation
  • Friction surface area features non-directional finish, which improves brake rotor and pad break-in
  • Precision-machined non-frictional surfaces for rotor balance and cleaner look
  • With high-quality protective coating for long-lasting rust protection
  • OE-style vane configurations provide thermal efficiency and proper heat transfer
Make American Motors
Model AMX, Hornet, Javelin, Rambler, Rebel
Year 1967

Product Description

C-Tek Standard Brake Rotor

Application Summary

American Motors AMX 1970-1968, Hornet 1970, Javelin 1970-1968, Rambler 1969, Rebel 1970-1967

Features & Benefits

  • Non-Directional Finishes. Machined non-friction surfaces. Widest application coverage in the aftermarket

C-Tek; Centric; Standard brake rotor; brake rotor; break rotor; rotors; rotor

Product Attributes

Discard Thickness 11.430 MM
Nominal Thickness 0.507 IN
Overall Height 54.000 MM
Outside Diameter 284.000 MM
Mounting Bolt Hole Quantity 5
ABS Tone Ring Included No
Surface Type Smooth
Solid Or Vented Type Rotor Solid
Bearings Included No
Center Hole Diameter 3.114 IN
Mounting Bolt Hole Circle Diameter 114.300 MM
Mounting Bolt Hole Diameter 16.500 MM
California Proposition 65 Site [basic] https://www.p65warnings.ca.gov/
California Proposition 65 Text [basic] WARNING: Cancer and Reproductive Harm
Disc Mounting [cntrc] Behind the Hub
Misc Holes [cntrc] 0
Weight [cntrc] Kgs 5.910
Weight [cntrc] Lbs 13.000

Additional Information

Country of Origin (Primary) CN
Harmonized Tariff Code (Schedule B) 8708300050
Harmonized Tariff Code (HTS) 8708305030
NAFTA Preference Criterion Code B
UPC 00805890305156

Fits Vehicles

  • American Motors Hornet (1970)
  • American Motors AMX (1968-1970)
  • American Motors Rambler (1969)
  • American Motors Javelin (1968-1970)
  • American Motors Rebel (1967-1970)

Formed in 2017, Centric® brings two of the industry’s leading undercar parts manufacturers, AP Emissions Technologies and Centric Brakes, under one brand. The merger combines more than 90 years’ worth of experience in aftermarket performance exhaust solutions with market leadership in brakes and chassis systems, resulting in an extensive portfolio of undercar components made available to distribution partners worldwide. From brake discs to catalytic converters, APC-Centric products make use of high-quality materials precision engineering to provide reliable performance at a reasonable cost to the customer. Also, as part of the larger APC Automotive Technologies group, APC-Centric has the competitive advantage of vertically-integrated supply chain and access to a global network of R&D, testing, and manufacturing facilities and customer support channels.
