(888) 312-8812 Login SignupCENTRIC 121.63014 C-Tek Standard Brake Rotor
Tap to view 4 more
$28.05
MSRP Pricing shown.
Out of Stock
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
CENTRIC 121.63014 Part Description
Manufacturer
Product Description
C-Tek Standard Brake Rotor
Features & Benefits
- Non-Directional Finishes. Machined non-friction surfaces. Widest application coverage in the aftermarket
- For heat capacity and strength
- OE Vane Design & Plate Thickness
- Optimal Surface Finish
- For consistent stopping power
- Low Initial Lateral Run-Out and Disc-Thickness Variation
- For smooth, vibration free stopping
- Precision Balanced
- For vibration free performance
CENTRIC 121.63014 Specifications
Product Attributes
| Disc Mounting [cntrc] | Floating |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Weight [cntrc] Kgs | 4.550 |
| Vane Style [cntrc] | Straight |
| Misc Holes [cntrc] | 0 |
| Weight [cntrc] Lbs | 10.000 |
| Product Grade [cntrc] | Standard |
| Discard Thickness | 22.400 MM |
| Discard Thickness | 0.882 IN |
| Nominal Thickness | 24.000 MM |
| Nominal Thickness | 0.945 IN |
| Overall Height | 1.508 IN |
| Overall Height | 38.300 MM |
| Outside Diameter | 239.100 MM |
| Outside Diameter | 9.413 IN |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Bearings Included | No |
| Center Hole Diameter | 2.406 IN |
| Center Hole Diameter | 61.100 MM |
| Mounting Bolt Hole Circle Diameter | 3.937 IN |
| Mounting Bolt Hole Circle Diameter | 100.000 MM |
| Stud/Lug Hole Quantity | 4 |
| Stud/Lug Hole Diameter | 13.100 MM |
| Stud/Lug Hole Diameter | 0.516 IN |
| Hat Finish | Bare |
Additional Information
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| UPC | 00805890050094 |
CENTRIC 121.63014 Cross References
| Brand | Part Number |
|---|---|
| 7006, 107006, 107048, 7006RGS, 7048, 52-60742, 5260742, BD60548, BD60742 | |
| N/A | BD60548, BD60742, 52-60742, 5260742, E126-68-019, 5322, 5325, BR5322, BR5325, 6491570, 64 91 570, 5322G, 5325G, 107005, 4126695, 4126947, 4313592, 2925174, 2925175, 3549840, 141202, 141267, PRT1267, 103220, 103250, 85739, 85827, 4885739, 4885827, 545, 546, AR8314, AR8314E, D17048, D17106, E12668019, X50239, X50326, 27052, BR1350, 107006, 107006R, 107048, 7006, 7006R, 7006RGS, 7048, 7048R, 7832014, 78-32014, 8932014, 78932014, 65005, 60039001, 177649, 177658 |
| RAYBESTOS | 7006, 7006R |
CENTRIC 121.63014 Fits Vehicles
- Dodge Aries (1981-1987)
- Dodge 400 (1982)
- Chrysler Town & Country (1982)
- Chrysler LeBaron (1982)
- Plymouth Reliant (1981-1987)
