(888) 312-8812 Login SignupCENTRIC 121.36003 C-Tek Standard Brake Rotor
Tap to view 4 more
$3149
Limited availability at this price!
1 Day Lead Time
Get it by Monday, Aug 3
CENTRIC 121.36003 Part Description
Manufacturer
Product Description
C-Tek Standard Brake Rotor
Features & Benefits
- Non-Directional Finishes. Machined non-friction surfaces. Widest application coverage in the aftermarket
- For heat capacity and strength
- OE Vane Design & Plate Thickness
- Optimal Surface Finish
- For consistent stopping power
- Low Initial Lateral Run-Out and Disc-Thickness Variation
- For smooth, vibration free stopping
- Precision Balanced
- For vibration free performance
CENTRIC 121.36003 Specifications
Product Attributes
| Vane Style [cntrc] | Straight |
| Weight [cntrc] Lbs | 9.250 |
| Disc Mounting [cntrc] | Floating |
| Weight [cntrc] Kgs | 4.200 |
| Misc Holes [cntrc] | 3 |
| Product Grade [cntrc] | Standard |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Discard Thickness | 0.669 IN |
| Discard Thickness | 17.000 MM |
| Nominal Thickness | 19.800 MM |
| Nominal Thickness | 0.780 IN |
| Overall Height | 1.614 IN |
| Overall Height | 41.000 MM |
| Outside Diameter | 236.000 MM |
| Outside Diameter | 9.291 IN |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Bearings Included | No |
| Center Hole Diameter | 60.000 MM |
| Center Hole Diameter | 2.362 IN |
| Mounting Bolt Hole Circle Diameter | 100.000 MM |
| Mounting Bolt Hole Circle Diameter | 3.937 IN |
| Stud/Lug Hole Quantity | 4 |
| Stud/Lug Hole Diameter | 0.559 IN |
| Stud/Lug Hole Diameter | 14.200 MM |
| Hat Finish | Bare |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00805890046479 |
CENTRIC 121.36003 Cross References
| Brand | Part Number |
|---|---|
| 1056170, 56170RGS, 56170, 52-125151, 52125151, BD125151 | |
| MAGMA PRODUCTS | PMR223048 |
| N/A | FR09021, 52-125151, BD125151, 52125151, 0802392, 0832392, 420115, 520115, 31017, BR31017, 6493290, 64 93 290, 63335, 31017G, 106511, 9195985, 94667868, 96471274, 90008006, 90008032, 90121445, 96574633, 569021, 569031, 569054, 93281952, 90511111, 141743, PRT1743, 102171, 85966, 86170, 4886170, BFR133410, 488, DF1609, DF4439, DF7217, EBR278, EBR278E, D17566, 1.3406.2.4, 1340624, OP061V, YH141743, X50672, 09748880, A4999, 25502, BR1601, 56170, 56170R, 56170RGS, 1056170, 1056170R, DDF1279, DDF151, DDF1130, 78-78002, 7878002, 78978002, 8978002, 142504, 60047000, 2235 |
| PRONTO | BR31017 |
| RAYBESTOS | 56170R |
| WAGNER | BD125151 |
CENTRIC 121.36003 Fits Vehicles
- Pontiac LeMans (1988-1993)
- Chevrolet Beat (2018-2020)
- Chevrolet Chevy Monza (2003)
- Chevrolet Chevy Pickup (1999-2003)
- Chevrolet Spark (2011-2015)
- Chevrolet Chevy (1994-2012)
