(888) 312-8812 Login SignupCENTRIC 120.67061 Centric Premium Brake Rotor
Tap to view 4 more
MSRP: $150.49
$11949
Save $31.00
Limited availability at this price!
In Stock
Get it by Wednesday, Jul 22
CENTRIC 120.67061 Part Description
Manufacturer
Product Description
Centric Premium Brake Rotor
Features & Benefits
- Symmetric vane; split-core castings for uniform heat distribution. Black E-Coat anti-corrosive coating protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life
- Painted hat and outer edge for corrosion resistance
- Symmetric vane; split-core castings for uniform heat distribution. Anti-corrosive paint protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life.
- Painted Hat and Outer Edge
- Optimal Surface Finish
- Optimal surface finish for consistent stopping feel from the first stop
- Advanced Metallurgy
- Advanced metallurgy for optimal heat transfer and structural strength
- OE Vane Design and Plate Thickness
- OE vane design and plate thickness for heat capacity and strength
- Low Initial Lateral Run-Out
- Low initial lateral run-out and disc thickness variation for smooth, vibration free stopping
- Precision Balance
- Precision balance for vibration free performance
CENTRIC 120.67061 Specifications
Product Attributes
| Disc Mounting [cntrc] | Floating |
| Vane Style [cntrc] | Straight |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Misc Holes [cntrc] | 0 |
| Weight [cntrc] Kgs | 15.910 |
| Weight [cntrc] Lbs | 35.000 |
| Product Grade [cntrc] | Premium |
| Discard Thickness | 34.000 MM |
| Discard Thickness | 1.339 IN |
| Nominal Thickness | 35.490 MM |
| Nominal Thickness | 1.397 IN |
| Hat Finish | Painted |
| Overall Height | 101.900 MM |
| Overall Height | 4.012 IN |
| Outside Diameter | 353.000 MM |
| Outside Diameter | 13.898 IN |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Bearings Included | No |
| Center Hole Diameter | 122.200 MM |
| Center Hole Diameter | 4.811 IN |
| Mounting Bolt Hole Circle Diameter | 6.500 IN |
| Mounting Bolt Hole Circle Diameter | 165.100 MM |
| Stud/Lug Hole Quantity | 8 |
| Stud/Lug Hole Diameter | 0.662 IN |
| Stud/Lug Hole Diameter | 16.810 MM |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 00805890136767 |
CENTRIC 120.67061 Cross References
| Brand | Part Number |
|---|---|
| 780143, BD126045 | |
| N/A | BD126045, BD126045E, E125-72-066, BR5301202, 53012, 53012G, 52121050AA, 5083697AA, 145456, 880143, AR8764, E12572066, E12396, 53012HC, 120.67061, 53012GT, 050AA, 0204202173, YH145456, 27384, 780143P, 2053012, 90040102 |
| NEOTEK | 107069GF |
| Neotek Premium Drums and Rotors | 107069GF |
| PRONTO | BR5301202 |
| RAYBESTOS | 780143, 780143FZN, 780143PER, 780143R, 780143R2 |
| Raybestos Brakes | 780143, 780143FZN, 780143PER, 780143R |
| WAGNER | BD125540, BD126045E, BD126045 |
CENTRIC 120.67061 Fits Vehicles
- Dodge Ram 4000 (2005-2008)
- Dodge Ram 1500 (2006-2008)
- Dodge Ram 3500 (2003-2008)
- Dodge Ram 2500 (2003-2008)
CENTRIC 120.67061 Customer Reviews
No reviews yet
Be the first to review this product!
CENTRIC 120.67061 Questions & Answers
No questions yet
Be the first to ask a question about this product!
