CENTRIC 120.66006 Part Description
Manufacturer
Product Description
Centric Premium Brake Rotor
Features & Benefits
- Symmetric vane; split-core castings for uniform heat distribution. Black E-Coat anti-corrosive coating protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life
- Painted hat and outer edge for corrosion resistance
- Symmetric vane; split-core castings for uniform heat distribution. Anti-corrosive paint protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life.
- Painted Hat and Outer Edge
- Optimal Surface Finish
- Optimal surface finish for consistent stopping feel from the first stop
- Advanced Metallurgy
- Advanced metallurgy for optimal heat transfer and structural strength
- OE Vane Design and Plate Thickness
- OE vane design and plate thickness for heat capacity and strength
- Low Initial Lateral Run-Out
- Low initial lateral run-out and disc thickness variation for smooth, vibration free stopping
- Precision Balance
- Precision balance for vibration free performance
CENTRIC 120.66006 Specifications
Product Attributes
| Vane Style [cntrc] | Straight |
| Weight [cntrc] Lbs | 14.200 |
| Disc Mounting [cntrc] | Floating |
| Weight [cntrc] Kgs | 6.450 |
| Misc Holes [cntrc] | 0 |
| Product Grade [cntrc] | Premium |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Discard Thickness | 24.300 MM |
| Discard Thickness | 0.957 IN |
| Nominal Thickness | 1.035 IN |
| Nominal Thickness | 26.300 MM |
| Hat Finish | Painted |
| Overall Height | 2.047 IN |
| Overall Height | 52.000 MM |
| Outside Diameter | 266.700 MM |
| Outside Diameter | 10.500 IN |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Bearings Included | No |
| Center Hole Diameter | 70.700 MM |
| Center Hole Diameter | 2.783 IN |
| Mounting Bolt Hole Circle Diameter | 120.600 MM |
| Mounting Bolt Hole Circle Diameter | 4.748 IN |
| Stud/Lug Hole Quantity | 5 |
| Stud/Lug Hole Diameter | 13.300 MM |
| Stud/Lug Hole Diameter | 0.524 IN |
Additional Information
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| UPC | 00805890043690 |
CENTRIC 120.66006 Cross References
| Brand | Part Number |
|---|---|
| 5036, BD102075 | |
| N/A | BD102075, E125-71-011, 6493295, 6493660, 64 93 660, 5550, 107209, 5550G, 1613287, 14056179, 15684318, 8156843180, 141261, 85668, 4885668, 515, AR8606, D5036, E8429, E12571011, 120.66006, 5550DSR, 5550DSL, YH141261, X50321, 27020, BR1020, 19717, 65195, 90048005, 177652, 177769, 18A60A |
| PRONTO | BR555002 |
| RAYBESTOS | 5036, 5036R |
| Raybestos Brakes | 5036, 5036R |
| WAGNER | BD102075 |
CENTRIC 120.66006 Fits Vehicles
- Oldsmobile Toronado (1979-1985)
- Oldsmobile Bravada (1991-1994, 1996)
- Cadillac Seville (1980-1985)
- Cadillac Eldorado (1979-1985)
- GMC Typhoon (1992-1993)
- GMC Syclone (1991)
- Buick Riviera (1979-1985)
- GMC Sonoma (1991-1997)
- GMC S15 (1983-1990)
- GMC Jimmy (1992-1997)
- GMC S15 Jimmy (1983-1991)
- Chevrolet S10 (1983-1997)
- Chevrolet Blazer (1995-1997)
- Chevrolet S10 Blazer (1983-1994)
