RAYBESTOS 5036 Raybestos Specialty - Street Performance Brake Rotor

★★★★★ (0)
Raybestos 5036 Disc Brake Rotor Raybestos Specialty - Street Performance Brake Rotor
RAYBESTOS

$125.99

Limited availability at this price!

In Stock

Get it by Thursday, Aug 27
No Hassle Return Policy Details
Free Ground shipping on orders over $499 details
Orders placed over the weekend will be processed the next business day.

RAYBESTOS 5036 Part Description

Manufacturer

RAYBESTOS

Product Description

Raybestos Specialty - Street Performance Brake Rotor

Application Summary

1997-1983 Chevrolet S10 Front, 1997-1991 GMC Sonoma Front, 1997-1995 Chevrolet Blazer Front, 1994-1983 Chevrolet S10 Blazer Front, 1997-1992 GMC Jimmy Front, 1990-1983 GMC S15 Front, 1985-1979 Cadillac Eldorado Front

Features & Benefits

  • Application Specific Enhanced Iron
  • Raybestos® Performance Rotors are made with enhanced iron which suppresses noise and keeps brakes running cool, quiet and vibration free.
  • Raybestos(R) Performance Rotors are made with enhanced iron which suppresses noise and keeps brakes running cool, quiet and vibration free.
  • Cooling Vanes
  • The cooling vanes match OE configurations and provide optimal cooling and reduced fade.
  • Application Specific Coating
  • Depending on the application, Performance Rotors will have one of the following finishes: Black fusion coating on the rotor hat Grey Fusion 4.0® coating on the entire rotor
  • Depending on the application, Performance Rotors will have one of the following finishes: Black fusion coating on the rotor hat Grey Fusion 4.0(R) coating on the entire rotor
  • Black fusion coating on the rotor hat and Grey Fusion 4.0® coating on the rotor inboard surface and cooling vanes
  • Black fusion coating on the rotor hat and Grey Fusion 4.0(R) coating on the rotor inboard surface and cooling vanes
  • Turned Finish
  • Turned finish minimizes noise and improves responsiveness for smoother stops.
  • S-Groove Slot
  • Depending on the application, some Raybestos® Performance Rotors are designed with a patented S-Groove Slot.
  • Depending on the application, some Raybestos(R) Performance Rotors are designed with a patented S-Groove Slot.

RAYBESTOS 5036 Specifications

Product Attributes

ABS Tone Ring Included No
Center Hole Diameter 2.79 IN
Center Hole Diameter 70.85 MM
Conventional Or Drum-In-Hat Type Rotor Conventional
Directional or Non-Directional Brake Surface Non-Directional
Discard Thickness 0.957 IN
Discard Thickness 24.3 MM
Harmonize Code 8708.30.5030
Material Cast Iron
Mounting Bolt Hole Circle Diameter 4.75 IN
Mounting Bolt Hole Circle Diameter 120.65 MM
Mounting Bolt Hole Diameter 0.511 IN
Mounting Bolt Hole Diameter 13 MM
Mounting Bolt Hole Quantity 5
Nominal Thickness 1.035 IN
Nominal Thickness 26.3 MM
Outside Diameter 10.5 IN
Outside Diameter 266.7 MM
Overall Height 2.05 IN
Overall Height 52.05 MM
Salability Restrictions No
Solid Or Vented Type Rotor Vented
Stud/Lug Hole Quantity 5
UNSPSC Code 25171715

Additional Information

Country of Origin (Primary) CN
Canadian Harmonizing Tariff Code 8708309990
Harmonized Tariff Code (HTS) 8708305030
UPC 00030999096258

RAYBESTOS 5036 Cross References

BrandPart Number
ACDELCO177-610, 177-652, 177-769
ADVANCE AUTO PARTS141261, YH141261
AMERICAN REMANUFACTURED789-44006, 89-44006
AUTOPART INTERNATIONAL25029
AUTOSPECIALTYAR8606, AR8606E
AUTOXTRA805036, AX5550
AUTOZONE5550, 5550B, DL5550
BENDIX141261, R448429
BOSCH25010550, RBR5550
BRAKE HEADQUARTERSBR55500
BRAKE PRO4615036
BRAKEBEST25010550, 5036, 5036R, 5036RGS, 81-102075, BD102075
BREMBO09.7512.80, 27020
Bridgestone7015520
CALIFORNIA DRUM & ROTOR102075
CENTRIC120.66006, 121.66006, 125.66006, 126.66006CSL, 126.66006CSR, 126.66006SL, 126.66006SR, 127.66006CL, 127.66006CR, 127.66006L, 127.66006R, 128.66006CL, 128.66006CR, 128.66006L, 128.66006R, 227.66006L, 227.66006R, 320.66006, 320.66006F
CENTURY5036
CERTIFIED DIVISIONHR122
CONTINENTAL-CONTITECHCW26701
Casting Numbers210226-C, 211503-DP, 325297, 4449, 55501, 635036
Centric Parts120.66006, 121.66006, 125.66006, 126.66006CSL, 126.66006CSR, 126.66006SL, 126.66006SR, 127.66006CL, 127.66006CR, 127.66006L, 127.66006R, 128.66006CL, 128.66006CR, 128.66006L, 128.66006R, 227.66006L, 227.66006R, 320.66006, 320.66006F
DAYTON WALTHERD4680
DELPHIRB534
DURA CORPBR5550, BR555002
DuraGoBR5550
EIS BRAKESD5036
EUCLIDE-8429
EUROROTOR5550
FADE FREE102075
GM14056179, 15684318, 1613287, 18027660
GREN681502
GUARDIAN52-102075
GUNITEG14680
General Motors14056179, 15684318, 1613287, 18027660
HOLLANDER1139
KELSEY HAYES14621, 14680
MAGMA PRODUCTSPSR225171
MCI5028, 5029, 5532
MERITORR44141261, R448429
MIDASBR1020
MIGHTY DISTRIBUTING SYSTEM5550
MONROE BRAKESBD102075
NEWTEK AUTOMOTIVE5532, 5550
Newtek Automotive USA5532, 5550
OmnicraftQBRR46
PARTS MASTERP102075
POWERSTOPAR8606EVC
PRAEFKE141188, 141261
PROMAX14-5550
PRONTOBR5550
QUALIS5550
QUALITEE INTERNATIONAL64-93-660
QUALITY BRAND5550
ROADMATES526036
ROCKHILL5550
SEARS1777, 510446
STANDARD ROTORS AND DRUMS5550
THE UNIVERSAL GROUP101500
TRUSTAR493660, R93660
TopNotchTN5036GEO
UAP5550
Universal101500
VIPAR - VEHICLE INDUSRTY PARTS & MANUFACTURINGX50321
WABCOPS102075
WABCO - ArchivedPS102075
WAGNERBD102075
WAGNER BRAKEBD102075
WINHERE442177, YH2177
WORLDPAC1427-732069

RAYBESTOS 5036 Fits Vehicles

  • Oldsmobile Toronado (1979-1985)
  • Oldsmobile Bravada (1991-1994, 1996)
  • GMC Syclone (1991)
  • GMC Typhoon (1992-1993)
  • GMC Sonoma (1991-1997)
  • GMC S15 (1983-1990)
  • GMC Jimmy (1992-1997)
  • GMC S15 Jimmy (1983-1991)
  • Chevrolet S10 (1983-1997)
  • Chevrolet Blazer (1995-1997)
  • Chevrolet S10 Blazer (1983-1994)
  • Cadillac Seville (1980-1985)
  • Cadillac Eldorado (1979-1985)
  • Buick Riviera (1979-1985)
