(888) 312-8812 Login SignupNTN WE61574 Wheel Bearing and Hub Assembly - Steel, Natural, with Wheel Studs
Tap to view 9 more
$39649
Limited Availability
Due to limited availability, we will confirm your order and notify you within 1 business day.
NTN WE61574 Part Description
Manufacturer
Product Description
OE form, fit & function wheel hub unit.
Features & Benefits
- All BCA applications that require ABS functionality utilize our custom-designed seals that are molded over with magnetic encoders (if required) to ensure proper ABS operation.
- Forged-steel construction provides the toughness and durability required for even the harshest applications.
- Rolling element cages reduce friction by keeping rolling elements spaced correctly, preventing damage and resulting in reduced operational temperatures.
- Application-specific components to ensure proper connection and performance of the ABS module and sensors.
- Pre-lubricated bearings, sealed for life with specialized grease provide longer life and a wider range of operational temperatures.
- Application-specific engineering reduces noise, vibration and harshness (NVH).
NTN WE61574 Specifications
Product Attributes
| Spline Quantity | 33 |
| Flange Bolt Hole Quantity | 3 |
| Wheel Pilot Diameter | 3.080 IN |
| Brake Pilot Diameter | 3.089 IN |
| Wheel Stud Quantity | 6 |
| Flange Shape | Modified Triangle |
| Anti Lock Braking System | Yes |
| Anti Lock Braking System Type | Tone Ring |
| Drive Type | Driven |
| Flange Offset | 1.972 IN |
| Bolt Circle Diameter | 5.500 IN |
| Knuckle Bolt Circle Diameter (Inches) | 4.913 |
| Knuckle Bolt Circle Diameter (Millimeters) | 124.8 |
| Knuckle Bolt Hole Size | M14x1.5 |
| Wheel Stud Size | M14x1.5 MM |
Additional Information
| Country of Origin (Primary) | US |
| Harmonized Tariff Code (Schedule B) | 8708995800 |
| Warranty Time | 12 |
| Warranty Time UOM | MO |
| UPC | 662810615746 |
NTN WE61574 Cross References
| Brand | Part Number |
|---|---|
| ACDelco | 515092 |
| Alltech Automotive | 515092 |
| Autopart International | 1411326087, 141149185 |
| CENTRIC | 402.66018, 402.66018E |
| CRS Automotive | NT515092 |
| Centric Parts | 402.66019E, 402.66019 |
| DT Components | 515092 |
| GMB | 7300350 |
| GSP | 106092 |
| General Motors | 15112450, 15058368 |
| MOOG Chassis Products | 515092 |
| MPA | WH515092 |
| Mevotech | H515092 |
| Power Train | PT515092 |
| Raybestos Brakes | 715092 |
| SKF | BR930671 |
| Schaeffler | FW792, 102197 |
| Timken | SP550309 |
| WJB | WA515092 |
NTN WE61574 Fits Vehicles
- GMC Safari (2003-2005)
- Chevrolet Astro (2003-2005)
