WABCO 4324130240 - AD-SysS 1200P Desiccant Cartridge Air Brake Dryer, with Coalescing Filter, Replaced by 4324210090
$78399
MSRP: $1,593.83
Save: $809.84
In stock
limited availability at this price!
. Learn more
WABCO part description
Product Description
SS1200P 12V A/D
Product Attributes
| Opening Pressure | 11.0 Bar |
| Voltage | 12 V |
| Port thread 1 | 1/2" - 14 NPTF |
| Port thread 4 | 1/4" - 18 NPTF |
| Max. operating pressure | 10.3 Bar |
| Heater | 8942600462 |
| Cut-Out Pressure | 7.9 to 9.0 Bar |
| Size | 335 x 242 x 183 |
| Weight | 9.35 |
| Silencer | No (432 407 012 0 Retrofittable) |
| Port thread 31 | Safety Valve |
| Calculated Volume (dm³) | 14.836 |
| Mounting | 3x 1/2" -13 UNC 2B |
| Port thread 22 | 1/4" - 18 NPTF |
| Port thread 21 | 1/2" - 14 NPTF |
| Heating Connection | Delphi Metri Pack 280 |
| Cooling | Compressed Air |
| Exhaust | Snap-On Contour |
| Port Thread 4/23 | 1/4" - 18 NPTF |
| Port thread 3 | JED- 463-0 |
| Temperature Range | -40°C to +80°C |
| Cartridge Type | Standard Cartridge M39 |
| Part Type | Premium Original Quality |
| Calculated Volume (Cubic Decimeter) | 14.836 |
| Comments | Turbo-Cut-Off Valve (TCV) Installed |
| Product Category | Set |
| Technical specification | OE Specification |
Part Interchanges
WABCO 4324130240 Cross Reference
We have 12 alternatives for the 4324130240 by WABCO:
Whether it’s for cars, buses, trucks, or trailers, WABCO® is at the frontline at developing and providing products and systems to make vehicles safer and easier to control. Founded in 1869, WABCO is a major supplier of braking, stability, suspension and transmissions in the Americas and beyond. The company is recognized as introducing the modern air brake system in 1869, and continues to lead the industry in air brake design and production for the heavy duty and commercial vehicle sectors. Today, WABCO operates as a division of the German auto parts maker ZF and employs 16,000 employees in facilities in 36 countries worldwide.
