(888) 312-8812 Login SignupWABCO 4324130240 AD-SysS 1200P Desiccant Cartridge Air Brake Dryer, with Coalescing Filter, Replaced by 4324210090
Tap to view 11 more
MSRP: $1,593.83
$91649
Save $677.34
Limited availability at this price!
In Stock
Get it by Tuesday, Aug 11
WABCO 4324130240 Part Description
Manufacturer
Product Description
SS1200P 12V A/D
Features & Benefits
- Desiccant media extracts moisture from compressed air flow
- Coalescing filter captures oil particles before they enter the system
- Cartridge-style design allows straightforward replacement during service
- Helps reduce contamination inside air brake components
- Designed for use with AD-SysS 1200P dryer systems
WABCO Air Brake Dryer
Moisture inside an air brake system can lead to contamination and freezing, and the WABCO Air Brake Dryer removes that moisture before it reaches critical components. This item uses desiccant material along with a coalescing filter to capture both water vapor and oil aerosols from compressed air. In daily driving, that process helps keep valves, lines, and reservoirs free from buildup that could affect braking response. Managing air quality within the system is the core function of the WABCO 4324130240.
WABCO 4324130240 Specifications
Product Attributes
| Opening Pressure | 11.0 Bar |
| Voltage | 12 V |
| Port thread 1 | 1/2" - 14 NPTF |
| Port thread 4 | 1/4" - 18 NPTF |
| Max. operating pressure | 10.3 Bar |
| Heater | 8942600462 |
| Cut-Out Pressure | 7.9 to 9.0 Bar |
| Size | 335 x 242 x 183 |
| Weight | 9.35 |
| Silencer | No (432 407 012 0 Retrofittable) |
| Port thread 31 | Safety Valve |
| Calculated Volume (dm³) | 14.836 |
| Mounting | 3x 1/2" -13 UNC 2B |
| Port thread 22 | 1/4" - 18 NPTF |
| Port thread 21 | 1/2" - 14 NPTF |
| Heating Connection | Delphi Metri Pack 280 |
| Cooling | Compressed Air |
| Exhaust | Snap-On Contour |
| Port Thread 4/23 | 1/4" - 18 NPTF |
| Port thread 3 | JED- 463-0 |
| Temperature Range | -40°C to +80°C |
| Cartridge Type | Standard Cartridge M39 |
| Part Type | Premium Original Quality |
| Calculated Volume (Cubic Decimeter) | 14.836 |
| Comments | Turbo-Cut-Off Valve (TCV) Installed |
| Product Category | Set |
| Technical specification | OE Specification |
WABCO 4324130240 Cross References
| Brand | Part Number |
|---|---|
| FREIGHTLINER | TDAS4324130240 |
| INTERNATIONAL | S4324130240 |
| International Harvester IHC | S4324130240 |
| KENWORTH | S432-413-024-0 |
| MACK | 6300-4324130240, 20377023 |
| MERITOR | S4324130240 |
| NAVISTAR | S4324130240 |
| PETERBILT | S432-413-024-0 |
| VOLVO | TDAS4324130240, WAB4324130240 |
| WABCO | S4324130240 |
| WABCO REMAN CORE | 4324210099 |
