CENTRIC 320.65148H Part Description
Manufacturer
Product Description
Centric GCX Rotor with Full Coating and High Carbon Content
Features & Benefits
- RS200 Coating our exclusive corrosion resistant coating for longer life and good looks; Iron Formulation Enhanced iron and high carbon metallurgies means the right rotor for your car; Operational Efficiency Full coverage with 80% fewer SKUs
CENTRIC 320.65148H Specifications
Product Attributes
| Hat Id [cntrc] Mm | 135.900 |
| OEM Vane Count [cntrc] | 90 |
| Product Grade [cntrc] | Premium |
| Weight [cntrc] Kgs | 11.180 |
| Weight [cntrc] Lbs | 24.650 |
| Hat Id [cntrc] In | 5.350 |
| Vane Style [cntrc] | Pillar |
| Misc Holes [cntrc] | 0 |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Disc Mounting [cntrc] | Behind the Hub |
| Discard Thickness | 1.102 IN |
| Discard Thickness | 28.000 MM |
| Nominal Thickness | 31.000 MM |
| Nominal Thickness | 1.220 IN |
| Disc Finish | Fully Coated |
| Hat Finish | Coated |
| Overall Height | 61.200 MM |
| Overall Height | 2.409 IN |
| Outside Diameter | 308.000 MM |
| Outside Diameter | 12.126 IN |
| Mounting Bolt Hole Quantity | 5 |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Bolt Thread Pitch | 1.500 MM |
| Bearings Included | No |
| Center Hole Diameter | 3.528 IN |
| Center Hole Diameter | 89.600 MM |
| Mounting Bolt Hole Circle Diameter | 113.600 MM |
| Mounting Bolt Hole Circle Diameter | 4.472 IN |
| Mounting Bolt Hole Diameter | 12.000 MM |
Additional Information
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 00889590393279 |
CENTRIC 320.65148H Cross References
CENTRIC 320.65148H Fits Vehicles
- Ford Transit-350 (2015-2023)
- Ford Transit-350 HD (2015-2023)
