(888) 312-8812 Login SignupCENTRIC 320.35017H Centric GCX Rotor with Full Coating and High Carbon Content
Tap to view 4 more
$6999
Limited availability at this price!
In Stock
Get it by Thursday, Jan 8
CENTRIC 320.35017H Part Description
Manufacturer
Product Description
Centric GCX Rotor with Full Coating and High Carbon Content
Features & Benefits
- RS200 Coating our exclusive corrosion resistant coating for longer life and good looks; Iron Formulation Enhanced iron and high carbon metallurgies means the right rotor for your car; Operational Efficiency Full coverage with 80% fewer SKUs
CENTRIC 320.35017H Specifications
Product Attributes
| Vane Style [cntrc] | Straight |
| Weight [cntrc] Lbs | 17.920 |
| Misc Holes [cntrc] | 5 |
| Weight [cntrc] Kgs | 8.150 |
| Disc Mounting [cntrc] | Behind the Hub |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Product Grade [cntrc] | Premium |
| Discard Thickness | 1.000 IN |
| Discard Thickness | 25.400 MM |
| Nominal Thickness | 27.900 MM |
| Nominal Thickness | 1.098 IN |
| Disc Finish | Fully Coated |
| Hat Finish | Coated |
| Overall Height | 68.200 MM |
| Overall Height | 2.685 IN |
| Outside Diameter | 300.000 MM |
| Outside Diameter | 11.811 IN |
| Mounting Bolt Hole Quantity | 5 |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Bearings Included | No |
| Center Hole Diameter | 80.000 MM |
| Center Hole Diameter | 3.150 IN |
| Mounting Bolt Hole Circle Diameter | 112.000 MM |
| Mounting Bolt Hole Circle Diameter | 4.409 IN |
| Mounting Bolt Hole Diameter | 15.000 MM |
| Mounting Bolt Hole Diameter | 0.591 IN |
Additional Information
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 889590387803 |
CENTRIC 320.35017H Part Interchanges
| Brand | Part Number |
|---|---|
| Raybestos Brakes | 96224R, 96224 |
CENTRIC 320.35017H Fits Vehicles
- Mercedes-Benz 560SEL (1986-1991)
- Mercedes-Benz 560SEC (1986-1991)
- Mercedes-Benz 420SEL (1986-1991)
- Mercedes-Benz 350SDL (1990-1991)
- Mercedes-Benz 350SD (1991)
- Mercedes-Benz 300SEL (1988-1991)
- Mercedes-Benz 300SE (1988-1991)
- Mercedes-Benz 300SDL (1986-1987)
- Mercedes-Benz 300SD (1985)
CENTRIC 320.35017H Cross References
We have 2 alternatives for the 320.35017H by CENTRIC:
CENTRIC 320.35017H Customer Reviews
No reviews yet
Be the first to review this product!
