CENTRIC 120.83015 Part Description
Manufacturer
Product Description
Centric Premium Brake Rotor
Features & Benefits
- Symmetric vane; split-core castings for uniform heat distribution. Black E-Coat anti-corrosive coating protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life
- Painted hat and outer edge for corrosion resistance
- Symmetric vane; split-core castings for uniform heat distribution. Anti-corrosive paint protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life.
- Painted Hat and Outer Edge
- Optimal Surface Finish
- Optimal surface finish for consistent stopping feel from the first stop
- Advanced Metallurgy
- Advanced metallurgy for optimal heat transfer and structural strength
- OE Vane Design and Plate Thickness
- OE vane design and plate thickness for heat capacity and strength
- Low Initial Lateral Run-Out
- Low initial lateral run-out and disc thickness variation for smooth, vibration free stopping
- Precision Balance
- Precision balance for vibration free performance
CENTRIC 120.83015 Specifications
Product Attributes
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Weight [cntrc] Lbs | 37.000 |
| Vane Style [cntrc] | Straight |
| Weight [cntrc] Kgs | 16.820 |
| Disc Mounting [cntrc] | Behind the Hub |
| Misc Holes [cntrc] | 0 |
| Product Grade [cntrc] | Premium |
| Notes [cntrc] | Hat Shaped, Cast in ABS Ring |
| Discard Thickness | 33.530 MM |
| Discard Thickness | 1.320 IN |
| Nominal Thickness | 1.437 IN |
| Nominal Thickness | 36.500 MM |
| Overall Height | 89.000 MM |
| Overall Height | 3.504 IN |
| Outside Diameter | 381.000 MM |
| Outside Diameter | 15.000 IN |
| Mounting Bolt Hole Quantity | 6 |
| ABS Tone Ring Included | Yes |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Bearings Included | No |
| Center Hole Diameter | 137.200 MM |
| Center Hole Diameter | 5.402 IN |
| Mounting Bolt Hole Circle Diameter | 6.752 IN |
| Mounting Bolt Hole Circle Diameter | 171.500 MM |
| Mounting Bolt Hole Diameter | 19.600 MM |
| Mounting Bolt Hole Diameter | 0.772 IN |
| Hat Finish | Painted |
Additional Information
| Harmonized Tariff Code (HTS) | 8708305030 |
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 00805890233015 |
CENTRIC 120.83015 Cross References
| Brand | Part Number |
|---|---|
| 8523R, BD126392, 2505097C1, 54770P65, W8000127, W8000261, W8002188, W8002188P, E6115, 23123572004, 23123572009, 54770F, 54770P | |
| EUCLID | E14572 |
| MERITOR | 23123572002 |
| N/A | BD126392, E125-88-020, 153123572, 54770F, 54770P, R44141475, R446115, 23123572004, 23123572009, 23123572, 0700021, 123572, 41296, 38108930, 0700021S1, 54770P65, 1646770C1, 2505097C1, W8000127, W8000261, W8002188, W8002188P, 19261459, 8523R, 3516567, B6194AM, D6194AM, E12588020, E6115 |
| NEOTEK | 1065017GF |
| Neotek Premium Drums and Rotors | 1065017GF |
| RAY | 8523 |
| RAYBESTOS | 8540, 8540R |
| Raybestos Brakes | 8523, 8540, 8540R |
| WAGNER | BD126392 |
| WEBB | 54770 |
CENTRIC 120.83015 Fits Vehicles
- Freightliner MCL (2011, 2014)
- Freightliner MC Line (2001, 2005-2019)
- Freightliner B2 (2005-2020)
- International 4400LP (2002-2008)
- International 4400 (2002-2008)
- International 4300LP (2002-2008)
- International 4300 (2002-2008)
- International 4200LP (2003-2007)
- International 3000 (1998-2002)
- Peterbilt 337 (2010-2012)
- Peterbilt 325 (2008-2010)
- International 1654 (1983-1989)
- International 4100 (2006-2008)
- International Genesis RE (1998-2002)
- Peterbilt 335 (2008-2010)
- Peterbilt 330 (2008-2012)
- International 3800 (1998-2004)
- International 1754 (1979-1989)
- International 1724 (1979-1985)
- International 3400 (1998-2002)
- International 3000IC (2000-2002)
- International 3000FE (1998-1999)
- International 1652UPS (1990-1991, 1993, 1995-1997)
- Freightliner FL70 (1998-2005)
- Freightliner FL60 (1998-2004)
- International S1754 (1981-1989)
- International S1753 (1984-1989)
- International S1724 (1980-1984)
- Freightliner M2 100 (2002-2006)
- International 3600 (1998-1999, 2001-2002)
- International 3000RE (1996-2002, 2005)
- International S1723 (1980-1985)
- International S1654LP (1988-1989)
- International S1654 (1984-1989)
- International 1452SC (1987-1992)
- Freightliner MT35 (1997-2009)
- Freightliner MB Line (1995-2022)
- Freightliner MT55 (1999-2018)
- Freightliner MT45 (1998-2019)
- International 4900 (1998-2005)
- Kenworth T370 (2008-2016)
- Kenworth T270 (2008-2016)
- Kenworth T300 (1999-2008)
- International 4800 (1998-2003)
- Kenworth T170 (2008-2016)
- Freightliner FS65 (1996-2008)
- International 4200 (2002-2008)
- International 4100 SBA (2006-2008)
- International 4700LPX (1998-2002)
- International 4700LP (1998-2002)
- International 4700 (1998-2005, 2008)
- International 1652SC (1986-2006)
- International 3200 (2002-2008)
- International 3300 (2005-2008)
- Freightliner M2 106 (2003-2020)
- Freightliner MB70 (1992-1994)
- Freightliner MB60 (1992-1994)
- Freightliner FL50 (1998-2005)
- Fleetwood Bounder Classic (2010, 2013)
- Fleetwood Bounder (2010)
- Blue Bird TC1000 (1997-2000)
- Workhorse W22 (2001-2009)
- Workhorse W21 (2007-2009)
- Workhorse W20 (2001-2009)
- Workhorse Custom Chassis W22 (2001-2011)
- Blue Bird SHL TC2000 (1993-2003)
- Blue Bird TC2000 (1989-2004)
