CENTRIC 120.83015 Disc Brake Rotor - 14.99" Outside Diameter, with Full Coating and High Carbon Content

★★★★★ (0)
Centric 120.83015 Disc Brake Rotor Disc Brake Rotor - 14.99" Outside Diameter, with Full Coating and High Carbon Content
CENTRIC
Tap to view 4 more

$287.49

Limited availability at this price!

In Stock

Get as soon as Tuesday, Nov 24
30-day Return Policy On eligible items Details
Free Ground shipping on orders over $499 details
Orders placed over the weekend will be processed the next business day.

CENTRIC 120.83015 Part Description

Manufacturer

CENTRIC

Product Description

Centric Premium Brake Rotor

Features & Benefits

  • Symmetric vane; split-core castings for uniform heat distribution. Black E-Coat anti-corrosive coating protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life
  • Painted hat and outer edge for corrosion resistance
  • Symmetric vane; split-core castings for uniform heat distribution. Anti-corrosive paint protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life.
  • Painted Hat and Outer Edge
  • Optimal Surface Finish
  • Optimal surface finish for consistent stopping feel from the first stop
  • Advanced Metallurgy
  • Advanced metallurgy for optimal heat transfer and structural strength
  • OE Vane Design and Plate Thickness
  • OE vane design and plate thickness for heat capacity and strength
  • Low Initial Lateral Run-Out
  • Low initial lateral run-out and disc thickness variation for smooth, vibration free stopping
  • Precision Balance
  • Precision balance for vibration free performance

CENTRIC 120.83015 Specifications

Product Attributes

California Proposition 65 Text [cntrc]WARNING: Cancer and Reproductive Harm
Weight [cntrc] Lbs37.000
Vane Style [cntrc]Straight
Weight [cntrc] Kgs16.820
Disc Mounting [cntrc]Behind the Hub
Misc Holes [cntrc]0
Product Grade [cntrc]Premium
Notes [cntrc]Hat Shaped, Cast in ABS Ring
Discard Thickness33.530 MM
Discard Thickness1.320 IN
Nominal Thickness1.437 IN
Nominal Thickness36.500 MM
Overall Height89.000 MM
Overall Height3.504 IN
Outside Diameter381.000 MM
Outside Diameter15.000 IN
Mounting Bolt Hole Quantity6
ABS Tone Ring IncludedYes
Surface TypeSmooth
Solid Or Vented Type RotorVented
Bearings IncludedNo
Center Hole Diameter137.200 MM
Center Hole Diameter5.402 IN
Mounting Bolt Hole Circle Diameter6.752 IN
Mounting Bolt Hole Circle Diameter171.500 MM
Mounting Bolt Hole Diameter19.600 MM
Mounting Bolt Hole Diameter0.772 IN
Hat FinishPainted

Additional Information

Harmonized Tariff Code (HTS)8708305030
Harmonized Tariff Code (Schedule B)8708300050
NAFTA Preference Criterion CodeB
Country of Origin (Primary)CN
UPC00805890233015

CENTRIC 120.83015 Cross References

BrandPart Number
8523R, BD126392, 2505097C1, 54770P65, W8000127, W8000261, W8002188, W8002188P, E6115, 23123572004, 23123572009, 54770F, 54770P
EUCLIDE14572
MERITOR23123572002
N/ABD126392, E125-88-020, 153123572, 54770F, 54770P, R44141475, R446115, 23123572004, 23123572009, 23123572, 0700021, 123572, 41296, 38108930, 0700021S1, 54770P65, 1646770C1, 2505097C1, W8000127, W8000261, W8002188, W8002188P, 19261459, 8523R, 3516567, B6194AM, D6194AM, E12588020, E6115
NEOTEK1065017GF
Neotek Premium Drums and Rotors1065017GF
RAY8523
RAYBESTOS8540, 8540R
Raybestos Brakes8523, 8540, 8540R
WAGNERBD126392
WEBB54770

CENTRIC 120.83015 Fits Vehicles

  • Freightliner B2 (2005-2020)
  • Freightliner FL50 (1998-2005)
  • Freightliner FL60 (1998-2004)
  • Freightliner FL70 (1998-2005)
  • Freightliner FS65 (1996-2008)
  • Freightliner M2 100 (2002-2006)
  • Freightliner M2 106 (2003-2020)
  • Freightliner MB Line (1995-2022)
  • Freightliner MB60 (1992-1994)
  • Freightliner MB70 (1992-1994)
  • Freightliner MC Line (2001, 2005-2019)
  • Freightliner MCL (2011, 2014)
  • Freightliner MT35 (1997-2009)
  • Freightliner MT45 (1998-2019)
  • Freightliner MT55 (1999-2018)
  • International 1452SC (1987-1992)
  • International 1652SC (1986-2006)
  • International 1652UPS (1990-1991, 1993, 1995-1997)
  • International 1654 (1983-1989)
  • International 1724 (1979-1985)
  • International 1754 (1979-1989)
  • International 3000 (1998-2002)
  • International 3000FE (1998-1999)
  • International 3000IC (2000-2002)
  • International 3000RE (1996-2002, 2005)
  • International 3200 (2002-2008)
  • International 3300 (2005-2008)
  • International 3400 (1998-2002)
  • International 3600 (1998-1999, 2001-2002)
  • International 3800 (1998-2004)
  • International 4100 (2006-2008)
  • International 4100 SBA (2006-2008)
  • International 4200 (2002-2008)
  • International 4200LP (2003-2007)
  • International 4300 (2002-2008)
  • International 4300LP (2002-2008)
  • International 4400 (2002-2008)
  • International 4400LP (2002-2008)
  • International 4700 (1998-2005, 2008)
  • International 4700LP (1998-2002)
  • International 4700LPX (1998-2002)
  • International 4800 (1998-2003)
  • International 4900 (1998-2005)
  • International Genesis RE (1998-2002)
  • International S1654 (1984-1989)
  • International S1654LP (1988-1989)
  • International S1723 (1980-1985)
  • International S1724 (1980-1984)
  • International S1753 (1984-1989)
  • International S1754 (1981-1989)
  • Kenworth T170 (2008-2016)
  • Kenworth T270 (2008-2016)
  • Kenworth T300 (1999-2008)
  • Kenworth T370 (2008-2016)
  • Peterbilt 325 (2008-2010)
  • Peterbilt 330 (2008-2012)
  • Peterbilt 335 (2008-2010)
  • Peterbilt 337 (2010-2012)
  • Blue Bird SHL TC2000 (1993-2003)
  • Blue Bird TC1000 (1997-2000)
  • Blue Bird TC2000 (1989-2004)
  • Fleetwood Bounder (2010)
  • Fleetwood Bounder Classic (2010, 2013)
  • Workhorse Custom Chassis W22 (2001-2011)
  • Workhorse W20 (2001-2009)
  • Workhorse W21 (2007-2009)
  • Workhorse W22 (2001-2009)
