(888) 312-8812 Login SignupCENTRIC 320.33022H Centric GCX Rotor with Full Coating and High Carbon Content
Tap to view 4 more
$5049
Limited availability at this price!
In Stock
Get it by Tuesday, Dec 16
CENTRIC 320.33022H Part Description
Manufacturer
Product Description
Centric GCX Rotor with Full Coating and High Carbon Content
Features & Benefits
- RS200 Coating our exclusive corrosion resistant coating for longer life and good looks; Iron Formulation Enhanced iron and high carbon metallurgies means the right rotor for your car; Operational Efficiency Full coverage with 80% fewer SKUs
CENTRIC 320.33022H Specifications
Product Attributes
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Inner Bearing # [cntrc] | 410.91015 |
| Weight [cntrc] Lbs | 9.990 |
| Disc Mounting [cntrc] | Hub & Rotor |
| Inner Seal # [cntrc] | 417.33000 |
| Misc Holes [cntrc] | 0 |
| Weight [cntrc] Kgs | 4.540 |
| Outer Bearing # [cntrc] | 410.91001 |
| Product Grade [cntrc] | Premium |
| Discard Thickness | 8.000 MM |
| Discard Thickness | 0.315 IN |
| Nominal Thickness | 10.000 MM |
| Nominal Thickness | 0.394 IN |
| Disc Finish | Fully Coated |
| Hat Finish | Coated |
| Overall Height | 71.300 MM |
| Overall Height | 2.807 IN |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Rotor Outside Diameter | 226.000 MM |
| Rotor Outside Diameter | 8.898 in |
| Solid Or Vented Type Rotor | Solid |
| Bolt Thread Pitch | 1.500 MM |
| Bearings Included | No |
| Center Hole Diameter | 57.100 MM |
| Center Hole Diameter | 2.248 IN |
| Mounting Bolt Hole Circle Diameter | 100.000 MM |
| Mounting Bolt Hole Circle Diameter | 3.937 IN |
| Mounting Bolt Hole Diameter | 12.000 MM |
| Stud/Lug Hole Quantity | 4 |
Additional Information
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 889590386646 |
CENTRIC 320.33022H Part Interchanges
| Brand | Part Number |
|---|---|
| Raybestos Brakes | 9934FZN, 9934R |
CENTRIC 320.33022H Fits Vehicles
- Volkswagen Cabrio (1999-2002)
- Volkswagen Passat (1990-1993, 1995-1997)
- Volkswagen Corrado (1990-1991)
- Volkswagen Scirocco (1986-1989)
- Volkswagen Jetta (1985-1998)
- Volkswagen Golf (1985-1998)
CENTRIC 320.33022H Cross References
We have 2 alternatives for the 320.33022H by CENTRIC:
