DORMAN BJ85536 Part Description
Manufacturer
Product Description
Suspension Ball Joint
Application Summary
Ford Explorer 2005-02, Lincoln Aviator 2005-03, Mercury Mountaineer 2005-02
Features & Benefits
- Direct replacement - fits and performs like the original equipment on specific vehicles
- Reliable fit - precision-engineered to match the design and dimensions of original components
- Durable construction - manufactured to strict standards using sturdy, safe materials
- Rigorously tested - thorough quality control measures ensure longevity
Suspension, Ball, Joint, Joints, Balls, Suspensions
DORMAN BJ85536 Specifications
Product Attributes
| Material | Steel |
| Stud Thread Diameter | 19.5 MM |
| Castle Nut Included | No |
| Suspension Grade Type | Standard |
| Cotter Pin Hole | Non |
| Mounting Hardware Included | Oui |
| Mounting Hole Quantity | 0 |
| Adjustable | No |
| Greaseable | Yes |
| Stud Type | Pinch |
| Mounting Type | A presion |
| Dust Boot Material | Caucho |
| Attachment Type | Pinchar |
| Bearing Material | Acero |
| Bolts/Studs Included | Oui |
| Housing Press Fit Diameter | 42.6 mm |
| Package Contents | 1 Ball Joint |
| Thread Pitch | M1.5 |
| Length | 111 MM |
| Color | Grey |
| Width | 59 MM |
| Type | Roscado |
| Height | 85.03 MM |
| Wrench Size | 12 mm MM |
| Maximum Outside Diameter | 61 MM |
| Grease Fitting Included | No |
| Bushings Included | No |
| Dust Boot Included | Si |
| Ball Joint Assembly | Yes |
| Cotter Pin Included | Non |
| Washers Included | No |
| Nuts Included | Oui |
| Stud Thread Length | 35.5 MM |
| Bushing Quantity | 0 |
| Mounting Bolts Included | No |
| Mount Plate Included | No |
| Tapered Stud | Yes |
| Stud Taper Per Foot | 2 IN |
| Stud Tapered End 2 Diameter | 22 MM |
| Stud Tapered End 1 Diameter | 27.2 MM |
| Stud Thread Pitch | 1.5 MM |
| Articulación de rótula instalada | Si |
| Ball Joint Installed | Oui |
| Bushing Included | No |
| Contenidos del paquete | 1 rotula |
| Diámetro del acoplado a presión de la caja | 42.6 mm mm |
| Housing Press Fit Diameter | 42.6 mm MM |
| Pernos/argollas incluidos | Si |
| Thread Pitch | M1.5 mm |
| Diámetro de la rosca de la argolla | 19.5mm MM |
| Espacio de la rosca del espárrago | 1,5mm MM |
| Nuts Included | Si |
| Paso de rosca | M1.5 MM |
| Stud Thread Diameter | 19.5 mm MM |
| Stud Thread Pitch | 1.5 mm MM |
Additional Information
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (Schedule B) | 8708807000 |
| Warranty Special | Limited |
| Warranty Special UOM | LF |
| UPC | 00843295086195 |
| VMRS Code | 016001015 |
| UNSPSC | 25174203 |
DORMAN BJ85536 Cross References
| Brand | Part Number |
|---|---|
| ACDelco | 45D0124 |
| Centric Parts | 610.65043 |
| DORMAN | 535-638 |
| Delphi | TC5359 |
| Ford | 1L2Z5500AC |
| MEVOTECH | MS40517 |
| MOOG | K500109 |
| MOOG Chassis Products | K500109, K500169 |
| Mcquay-Norris | FA2246, FA2246E |
| Mevotech Original Grade | GS40517 |
| Mevotech Supreme | MS40517 |
| QUICK STEER | K500109 |
| QuickSteer | K500109 |
| SUSPENSIA | X15BJ7233 |
| SYD | 1008022 |
| TRW | JBJ503 |
| XRF | K500109 |
| XRF Chassis | K500109 |
DORMAN BJ85536 Fits Vehicles
- Mercury Mountaineer (2002-2005)
- Lincoln Aviator (2003-2005)
- Ford Explorer (2002-2005)
