(888) 312-8812 Login SignupWABCO 9617231020 Parking Brake Valve - Hand Brake Valve
Tap to view 3 more
$2,22249
14 Day Lead Time
Due to limited availability, we will confirm your order and notify you within 1 business day.
WABCO 9617231020 Part Description
WABCO 9617231020 Specifications
Product Attributes
| Calculated Volume (dm³) | 1.1 |
| Weight | 1.3426 |
| Max. operating pressure | 10.0 bar |
| Max. operating pressure | 145.04 psi |
| Size | 178 x 103 x 60 |
| Temperature Range | -40°C to +80°C |
| Actuation Angle | 73° |
| Distance Between Holes | 80 mm |
| Parking Position | 73° |
| Color | Black/Black |
| Exhaust | Hose Nozzle Ø 6 mm |
| Port thread 1 | M16 x 1.5 JED - 464 |
| Port thread 21 | M16 x 1.5 JED - 464 |
| Port thread 22 | M16 x 1.5 JED - 464 |
| Port threads | M16 x 1.5 VOSS |
| Mounting | M6 |
WABCO 9617231020 Cross References
We have 1 alternatives for the 9617231020 by WABCO:
WABCO 9617231020 Manufacturer Information
Whether it’s for cars, buses, trucks, or trailers, WABCO® is at the frontline at developing and providing products and systems to make vehicles safer and easier to control. Founded in 1869, WABCO is a major supplier of braking, stability, suspension and transmissions in the Americas and beyond. The company is recognized as introducing the modern air brake system in 1869, and continues to lead the industry in air brake design and production for the heavy duty and commercial vehicle sectors. Today, WABCO operates as a division of the German auto parts maker ZF and employs 16,000 employees in facilities in 36 countries worldwide.
