(888) 312-8812 Login SignupWABCO 4005000700 Trailer ABS Valve and Electronic Control Unit Assembly
Tap to view 4 more
$1,38449
21 Day Lead Time
Due to limited availability, we will confirm your order and notify you within 1 business day.
WABCO 4005000700 Part Description
Manufacturer
Features & Benefits
- Standard 24-volt electrical system compatibility for heavy commercial trailers
- Integrated 2S/2M layout combining ECU functions and pneumatic modulation
- IP66-rated housing helps resist dust, moisture, and under-chassis contaminants
- Multi-pin DIN connectors simplify integration with compatible wheel speed sensors
WABCO Trailer ABS Valve and Electronic Control Unit Assembly
The WABCO Trailer ABS Valve and Electronic Control Unit Assembly replaces a combined modulator and electronic controller when wear or electrical faults begin affecting trailer ABS performance. Because both components are integrated into a single housing, a problem in either the electronic controller or pneumatic valve requires replacement of the complete assembly rather than individual internal parts. Restoring both functions together allows wheel speed inputs and brake pressure modulation to remain synchronized during ABS intervention. Replacing the original unit with the WABCO 4005000700 restores that factory-matched coordination, helping the trailer maintain stable, consistent braking when traction changes suddenly.
WABCO 4005000700 Specifications
Product Attributes
| Voltage | 24 V |
| System | 2S/2M |
| Port thread 21 | 3x M16 x 1.5 |
| Port thread 22 | 3x M16 x 1.5 |
| Calculated Volume (dm³) | 4.353 |
| Temperature Range | -40°C to +65°C |
| Version | VCS II |
| Max. operating pressure | 13.0 bar |
| Electrical connection | X1 = 8-Pole. X6 = 8-Pole. 2x Sensor Connector |
| Size | 223 x 131 x 149 |
| Port thread 1 | 2x M26 x 1.5 |
| Protection class | IP 66 |
| Type | Standard |
| Port thread 4 | M16 x 1.5 |
| Weight | 5.1985 |
| Port thread 3 | Flap Exhaust |
WABCO 4005000700 Cross References
| Brand | Part Number |
|---|---|
| BENALU | C00203202 |
| DAF | 1506760 |
| DOLL | 7118060 |
| FELDBINDER | 1036691 |
| FRUEHAUF | C00203202 |
| HAMANA WORKS | GV66000010 |
| KRONE | 5818838, 5058188380, 505818838 |
| KÖGEL | 6501232 |
| LECITRAILER | 4301161 |
| LIEBHERR | 10170572 |
| LOHR | A05101398 |
| NIPPON TREX | 924301-00100 |
| OTOKAR | AIF1187 |
| PACCAR | 1527244 |
| SCANIA | 1932574, 1738449 |
| SCHMITZ | 1002739 |
| SCHWARZMÜLLER | 79735 |
| VOLVO | WA4005000700 |
