(888) 312-8812 Login SignupDELPHI TC1605 Ball Joint
Tap to view 2 more
MSRP: $43.66
$3899
Save $4.67
Limited availability at this price!
In Stock
Get it by Friday, Dec 19
DELPHI TC1605 Part Description
DELPHI TC1605 Specifications
Product Attributes
| Position(s) | Front Lower |
| Item Grade | Standard Replacement |
| Material | Steel |
| Maximum Outside Diameter | 2.323 IN |
| Maximum Outside Diameter | 59.00 MM |
| Color | Gray |
| Stud Thread Diameter | 0.625 IN |
| Stud Thread Diameter | 15.875 MM |
| Castle Nut Included | Yes |
| Grease Fitting Included | Yes |
| Suspension Grade Type | Standard |
| Bushings Included | No |
| Dust Boot Included | Yes |
| Ball Joint Assembly | Yes |
| Width | 59 MM |
| Cotter Pin Included | Yes |
| Cotter Pin Hole | Yes |
| Mounting Hardware Included | Yes |
| Washers Included | No |
| Height | 5.118 IN |
| Height | 130.00 MM |
| Nuts Included | Yes |
| Mounting Hole Quantity | 0 |
| Adjustable | No |
| Stud Thread Length | 1.102 IN |
| Stud Thread Length | 28 MM |
| Wrench Size | 24mm |
| Stud Type | Threaded |
| Mounting Type | Press-In |
| Dust Boot Material | Rubber |
| Mount Plate Included | No |
| Tapered Stud | Yes |
| Stud Tapered End 2 Diameter | 0.89 IN |
| Stud Tapered End 2 Diameter | 22.6 MM |
| Stud Tapered End 1 Diameter | 0.685 IN |
| Stud Tapered End 1 Diameter | 17.4 MM |
| Stud Threads Per Inch | 18 |
| Length | 59.00 MM |
| Length | 2.320 IN |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708807000 |
| Harmonized Tariff Code (HTS) | 8708806590 |
| Warranty Special | Limited Lifetime |
| Warranty Special UOM | LF |
| Country of Origin (Primary) | TR |
| UPC | 00689604278598 |
| VMRS Code | 016001015 |
| UNSPSC | 25174203 |
DELPHI TC1605 Part Interchanges
| Brand | Part Number |
|---|---|
| MOOG Chassis Products | K6117T |
| Mevotech | MK6117T |
| General Motors | 9766423 |
| MAS Industries | B6117 |
| TRW | JBJ839 |
| N/A | 7810314, GK6117T, B6117PR, 7813722, 9758255 |
DELPHI TC1605 Fits Vehicles
- GMC P15/P1500 Van (1971-1974)
- GMC G25/G2500 Van (1973-1974)
- GMC G15/G1500 Van (1971-1974)
- GMC C15/C1500 Suburban (1971-1974)
- GMC C15/C1500 Pickup (1971-1974)
- Chevrolet P10 Van (1971-1974)
- Chevrolet G20 Van (1973-1974)
- Chevrolet G10 Van (1971-1974)
- Chevrolet C10 Pickup (1971-1974)
- Chevrolet Blazer (1971-1974)
- GMC R1500 Suburban (1987-1991)
- GMC R1500 (1987)
- GMC P3500 (1991-1997)
- GMC P1500 (1979-1980)
- GMC P15 (1975-1978)
- GMC Jimmy (1971-1982)
- GMC G25 (1975-1978)
- GMC G15 (1975-1978)
- GMC C1500 Suburban (1979-1986)
- GMC C15 Suburban (1975-1978)
- GMC C1500 (1979-1986)
- GMC C15 (1975-1978)
- Chevrolet R1500 Suburban (1989-1991)
- Chevrolet R10 Suburban (1987-1988)
- Chevrolet R10 (1987)
- Chevrolet P30 (1991-1997)
- Chevrolet P10 (1975-1980)
- Chevrolet C10 Suburban (1971-1986)
- Chevrolet C10 (1975-1986)
- Chevrolet K5 Blazer (1975-1982)
- GMC G2500 (1979-1995)
- GMC G1500 (1979-1995)
- Chevrolet G20 (1975-1995)
- Chevrolet G10 (1975-1995)
