Delphi TC438 - Ball Joint
$2249
MSRP: $27.00
Save: $4.51
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
DELPHI part description
Product Description
Ball Joint
Product Attributes
| Item Grade | Standard Replacement |
| Position(s) | Front Lower |
| Material | Steel |
| Maximum Outside Diameter | 3.150 IN |
| Maximum Outside Diameter | 80.00 MM |
| Castle Nut Included | No |
| Grease Fitting Included | No |
| Suspension Grade Type | Standard |
| Bushings Included | No |
| Dust Boot Included | Yes |
| Ball Joint Assembly | Yes |
| Width | 80 MM |
| Type | Premium |
| Cotter Pin Included | No |
| Cotter Pin Hole | No |
| Mounting Hardware Included | Yes |
| Mounting Bolt Length | 1.193 IN |
| Mounting Bolt Length | 30.30 MM |
| Washers Included | Yes |
| Height | 3.071 IN |
| Height | 78.00 MM |
| Nuts Included | Yes |
| Mounting Hole Quantity | 3 |
| Adjustable | No |
| Greaseable | No |
| Stud Thread Length | 0.768 IN |
| Stud Thread Length | 19.5 MM |
| Stud Type | Threaded |
| Mounting Type | Bolt-In |
| Distance Between Mounting Holes | 58.00 MM |
| Dust Boot Material | Rubber |
| Bushing Quantity | 0 |
| Mounting Bolt Shank Diameter | 0.335 IN |
| Mounting Bolt Shank Diameter | 8.50 MM |
| Mounting Bolt Head Diameter | 0.591 IN |
| Mounting Bolt Head Diameter | 15.00 MM |
| Mounting Bolts Included | Yes |
| Mounting Bolt Thread Pitch | 1.25 MM |
| Mounting Bolt Thread Length | 0.984 IN |
| Mounting Bolt Thread Length | 25.00 MM |
| Mount Plate Included | Yes |
| Tapered Stud | Yes |
| Stud Tapered End 2 Diameter | 0.646 IN |
| Stud Tapered End 2 Diameter | 16.4 MM |
| Stud Tapered End 1 Diameter | 0.724 IN |
| Stud Tapered End 1 Diameter | 18.4 MM |
| Stud Thread Pitch | 1.5 MM |
| Length | 81.00 MM |
| Length | 3.190 IN |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708807000 |
| Harmonized Tariff Code (HTS) | 8708806590 |
| Warranty Special | Limited Lifetime |
| Warranty Special UOM | LF |
| Country of Origin (Primary) | TR |
| UPC | 00689604259436 |
| VMRS Code | 016001015 |
| UNSPSC | 25174203 |
Part Interchanges
Fits Vehicles
- Volkswagen Golf (1995-1999)
- Volkswagen Jetta (1994-1999)
- Volkswagen Passat (1993-1997)
- Volkswagen Corrado (1992-1995)
