(888) 312-8812 Login SignupMONROE 37345 OESpectrum Suspension Shock Absorber
Tap to view 3 more
MSRP: $99.88
$6249
Save $37.39
Limited availability at this price!
In Stock
Get it by Thursday, Feb 19
MONROE 37345 Part Description
Manufacturer
Product Description
OESpectrum Suspension Shock Absorber
Features & Benefits
- EXCEPTIONAL HANDLING -- Full displaced valving, tuned specifically to each vehicle, adjusts to road extremes while the larger bore provides more efficient damping control to provide consistency and a smooth ride
- CONTROL AND DURABILITY -- PTFE-banded piston provides consistent sealing between piston and pressure tube for better control and increased durability
- REDUCED NOISE, VIBRATION AND HARSHNESS -- Twin Technology™ Active Control System delivers exceptional control under most driving conditions while isolating impact-related noise, vibration and harshness
- IMPROVES PERFORMANCE -- Nitrogen gas-charge maintains tire-to-road contact for improved ride and handling by reducing aeration and shock fade
- CONSISTENT RIDE -- OE all-weather fluid contains special additives to assist with extreme temperatures and help reduce oil breakdown
- BUILT TO LAST -- Self-lubricating fluid seal retains gas and reduces excessive friction against the piston rod to help reduce premature wear
- BUY WITH CONFIDENCE -- Comes with Monroe’s Limited Lifetime Warranty and exclusive Feel the Difference™ Guarantee
- BUY WITH CONFIDENCE -- Comes with Monroe's Limited Lifetime Warranty and exclusive Feel the DifferenceTM Guarantee
MONROE 37345 Specifications
Product Attributes
| Lower Mount Code | LS99 |
| Upper Mount Code | LS99 |
| Dust Shield Included | Yes |
| Includes Bump Stop | Yes |
| Internal Rebound Bumper | No |
| Hydraulic Lockout | No |
| Part Description | Shock Absorber |
| Compressed Length | 11.77 IN |
| Extended Length | 18.03 in |
| Gas Charged | Yes |
| Lower Mount Type | Loop Bushing and Sleeve Mount - 5/8"-16MM Sleeve ID X 3.1/4" Sleeve OAL |
| Parts Pack(s) | None |
| Travel Length | 6.26 in |
| Upper Mount Type | Loop Bushing and Sleeve Mount - 5/8" Sleeve ID X 3.1/4" Sleeve OAL |
| Compressed Length | 299 MM |
| Extended Length | 458 MM |
| Travel Length | 159 MM |
| Shock Absorber Rod End Measuring Point | Center of Loop |
| Shock Absorber Body End Measuring Point | Center of Loop |
| Lower Mount Type | Loop (Eyelet) Bushing and Sleeve |
| Lower Mount Code | LS99 |
| Upper Mount Code | LS99 |
| Mounting Hardware Included | No |
| Grade Type | Premium |
| Active or Passive Suspension | Passive |
| Adjustable Compression | No |
| Adjustable Rebound | No |
| Adjustable Ride Height | No |
Additional Information
| MSDS Sheet Number | 01170 |
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708803000 |
| Harmonized Tariff Code (Schedule B) | 8708800050 |
| Harmonized Tariff Code (HTS) | 8708801600 |
| UPC | 00048598163721 |
| VMRS Code | 016008003 |
| UNSPSC | 25172011 |
MONROE 37345 Cross References
| Brand | Part Number |
|---|---|
| Autopart International | 2701603102 |
| Duralast | TS3340292B |
| FCS | 347070 |
| Ford | DV6Z18124C, DV6Z18124F, DV6Z18124G, DV6Z18124H, DV6Z18125B, DV6Z18125C, DV6Z18125D, DV6Z18125E, DV6Z18125F, KV6Z18124A, KV6Z18124C, KV6Z18125A, KV6Z18125F |
| KYB | 3450002, 3450025 |
| KYB AMERICA LLC. | 3450002 |
| MOTORCRAFT | ASH24583, ASH24649, ASH24581, ASH24582 |
| MasterPro Shocks and Struts | FD173 |
| Motorcraft | ASH85936, ASH85939 |
| NAPA Shocks | 37345, NS37345 |
| OEM | DV6Z18125F, DV6Z18125D, DV6Z18125E, DV6Z18125C, DV6Z18125B |
| PM Auto | PM6001542 |
| TRQ | SBA71180 |
MONROE 37345 Fits Vehicles
- Ford Transit Connect (2014-2023)
