MONROE 5522 Part Description
Manufacturer
Product Description
OESpectrum Suspension Shock Absorber
Features & Benefits
- REDUCED NOISE, VIBRATION AND HARSHNESS -- Twin Technology™ Active Control System delivers exceptional control under most driving conditions while isolating impact-related noise, vibration and harshness
- EXCEPTIONAL HANDLING -- Full displaced valving, tuned specifically to each vehicle, adjusts to road extremes while the larger bore provides more efficient damping control to provide consistency and a smooth ride
- CONTROL AND DURABILITY -- PTFE-banded piston provides consistent sealing between piston and pressure tube for better control and increased durability
- CONSISTENT RIDE -- OE all-weather fluid contains special additives to assist with extreme temperatures and help reduce oil breakdown
- IMPROVES PERFORMANCE -- Nitrogen gas-charge maintains tire-to-road contact for improved ride and handling by reducing aeration and shock fade
- BUILT TO LAST -- Self-lubricating fluid seal retains gas and reduces excessive friction against the piston rod to help reduce premature wear
- BUY WITH CONFIDENCE -- Comes with Monroe’s Limited Lifetime Warranty and exclusive Feel the Difference™ Guarantee
MONROE 5522 Specifications
Product Attributes
| Lower Mount Code | LS44 |
| Upper Mount Code | S1 |
| Dust Shield Included | No |
| Includes Bump Stop | No |
| Internal Rebound Bumper | Yes |
| Hydraulic Lockout | No |
| Part Description | Shock Absorber |
| Body Diameter | 1.771 IN |
| Compressed Length | 14.466 IN |
| Extended Length | 21.023 in |
| Gas Charged | Yes |
| Lower Mount Type | Loop Bushing and Sleeve Mount - 14MM Sleeve ID X 1.7/8" Sleeve OAL |
| Parts Pack(s) | P01699 |
| Travel Length | 6.457 in |
| Upper Mount Type | Stem Mount - Stem Length X M10 Thread Pitch |
Additional Information
| MSDS Sheet Number | 1164 |
| Country of Origin (Primary) | PL |
| Canadian Harmonizing Tariff Code | 8708803000 |
| Harmonized Tariff Code (Schedule B) | 8708801600 |
| Harmonized Tariff Code (HTS) | 8708801600 |
| UPC | 00048598175724 |
| VMRS Code | 016008003 |
| UNSPSC | 25172011 |
MONROE 5522 Cross References
| Brand | Part Number |
|---|---|
| NAPA Shocks | 5522 |
| OEM | 314060110 |
| SACHS NORTH AMERICA | 314722 |
| Sachs | 314722 |
| Volvo | 312582300, 312582310, 312582320, 312773700, 312773710, 312773720, 312776260, 312776270, 312776640, 312777820, 312903270, 312903280, 312903290, 312903300, 312903350, 312903360, 313026040, 313174600, 313403220, 313403230, 313404730, 313404740, 313404750, 313404760, 313404770, 313404780, 313404790, 313404800, 313404810, 313404820, 313404830, 313404840, 313405400, 314060110, 314060120, 314060130, 314060140, 314103730, 314103740 |
MONROE 5522 Fits Vehicles
- Volvo XC60 (2010-2017)
