CENTRIC 320.45066 Part Description
Manufacturer
Product Description
Centric GCX Rotor with Partial Coating
Features & Benefits
- RS200 Coating our exclusive corrosion resistant coating for longer life and good looks; Iron FormulationEnhanced iron and high carbon metallurgies means the right rotor for your car; Operational Efficiency Full coverage with 80% fewer SKUs
CENTRIC 320.45066 Specifications
Product Attributes
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Hat Id [cntrc] Mm | 151.000 |
| Hat Id [cntrc] In | 5.945 |
| Weight [cntrc] Lbs | 8.500 |
| Weight [cntrc] Kgs | 3.860 |
| Product Grade [cntrc] | Premium |
| Disc Mounting [cntrc] | Floating |
| Misc Holes [cntrc] | 0 |
| Discard Thickness | 0.354 IN |
| Discard Thickness | 9.000 MM |
| Nominal Thickness | 0.433 IN |
| Nominal Thickness | 11.000 MM |
| Disc Finish | Partially Coated |
| Hat Finish | Coated |
| Overall Height | 41.000 MM |
| Overall Height | 1.614 IN |
| Outside Diameter | 10.433 IN |
| Outside Diameter | 265.000 MM |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Solid |
| Bearings Included | No |
| Center Hole Diameter | 71.800 MM |
| Center Hole Diameter | 2.827 IN |
| Mounting Bolt Hole Circle Diameter | 114.300 MM |
| Mounting Bolt Hole Circle Diameter | 4.500 IN |
| Stud/Lug Hole Quantity | 5 |
| Stud/Lug Hole Diameter | 13.000 MM |
| Stud/Lug Hole Diameter | 0.512 IN |
Additional Information
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 889590251432 |
CENTRIC 320.45066 Part Interchanges
| Brand | Part Number |
|---|---|
| Raybestos Brakes | 980285, 980285FZN, 980285R |
| N/A | 90080039, HC31365X |
