Centric 320.40064 - Centric GCX Rotor with Partial Coating
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
Sometimes we may have similar parts for sale, click the button below to see if anything matches.
CENTRIC part description
Product Description
Centric GCX Rotor with Partial Coating
Features & Benefits
- RS200 Coating our exclusive corrosion resistant coating for longer life and good looks; Iron FormulationEnhanced iron and high carbon metallurgies means the right rotor for your car; Operational Efficiency Full coverage with 80% fewer SKUs
Product Attributes
| Disc Mounting [cntrc] | Floating |
| Product Grade [cntrc] | Premium |
| Vane Style [cntrc] | Straight |
| Misc Holes [cntrc] | 4 |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Weight [cntrc] Lbs | 17.000 |
| Weight [cntrc] Kgs | 7.730 |
| Discard Thickness | 26.000 MM |
| Discard Thickness | 1.024 IN |
| Nominal Thickness | 27.900 MM |
| Nominal Thickness | 1.098 IN |
| Disc Finish | Partially Coated |
| Hat Finish | Coated |
| Overall Height | 47.500 MM |
| Overall Height | 1.870 IN |
| Outside Diameter | 296.100 MM |
| Outside Diameter | 11.657 IN |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Bearings Included | No |
| Center Hole Diameter | 2.764 IN |
| Center Hole Diameter | 70.200 MM |
| Mounting Bolt Hole Circle Diameter | 118.200 MM |
| Mounting Bolt Hole Circle Diameter | 4.654 IN |
| Stud/Lug Hole Quantity | 5 |
| Stud/Lug Hole Diameter | 14.600 MM |
| Stud/Lug Hole Diameter | 0.575 IN |
Additional Information
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 889590250565 |
Part Interchanges
CENTRIC 320.40064 Cross Reference
We have 3 alternatives for the 320.40064 by CENTRIC:
