RAYBESTOS 580770 Part Description
Manufacturer
Product Description
Raybestos Specialty - Street Performance Brake Rotor
Application Summary
2019-2010 Chevrolet Cruze Front, 2020-2012 Chevrolet Sonic Front, 2016 Chevrolet Cruze Limited Front, 2023-2017 Chevrolet Bolt EV Front, 2019-2016 Chevrolet Volt Front, 2023-2022 Chevrolet Bolt EUV Front
Features & Benefits
- Application Specific Enhanced Iron
- Raybestos® Performance Rotors are made with enhanced iron which suppresses noise and keeps brakes running cool, quiet and vibration free.
- Raybestos(R) Performance Rotors are made with enhanced iron which suppresses noise and keeps brakes running cool, quiet and vibration free.
- Cooling Vanes
- The cooling vanes match OE configurations and provide optimal cooling and reduced fade.
- Application Specific Coating
- Depending on the application, Performance Rotors will have one of the following finishes: Black fusion coating on the rotor hat Grey Fusion 4.0® coating on the entire rotor
- Depending on the application, Performance Rotors will have one of the following finishes: Black fusion coating on the rotor hat Grey Fusion 4.0(R) coating on the entire rotor
- Black fusion coating on the rotor hat and Grey Fusion 4.0® coating on the rotor inboard surface and cooling vanes
- Black fusion coating on the rotor hat and Grey Fusion 4.0(R) coating on the rotor inboard surface and cooling vanes
- Turned Finish
- Turned finish minimizes noise and improves responsiveness for smoother stops.
- S-Groove Slot
- Depending on the application, some Raybestos® Performance Rotors are designed with a patented S-Groove Slot.
- Depending on the application, some Raybestos(R) Performance Rotors are designed with a patented S-Groove Slot.
RAYBESTOS 580770 Specifications
Product Attributes
| ABS Tone Ring Included | No |
| Center Hole Diameter | 2.37 IN |
| Center Hole Diameter | 60.2 MM |
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
| Directional or Non-Directional Brake Surface | Non-Directional |
| Discard Thickness | 0.906 IN |
| Discard Thickness | 23 MM |
| Harmonize Code | 8708.30.5030 |
| Inside Diameter | 6.535 IN |
| Inside Diameter | 166 MM |
| Material | Cast Iron |
| Mounting Bolt Hole Circle Diameter | 4.134 IN |
| Mounting Bolt Hole Circle Diameter | 105 MM |
| Mounting Bolt Hole Diameter | 0.557 IN |
| Mounting Bolt Hole Diameter | 14.15 MM |
| Mounting Bolt Hole Quantity | 5 |
| Nominal Thickness | 1.024 IN |
| Nominal Thickness | 26 MM |
| Outside Diameter | 10.866 IN |
| Outside Diameter | 276 MM |
| Overall Height | 1.791 IN |
| Overall Height | 45.5 MM |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Vented |
| Stud/Lug Hole Quantity | 5 |
| Surface Type | Smooth |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708309990 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00887213170511 |
RAYBESTOS 580770 Cross References
| Brand | Part Number |
|---|---|
| ADVANCE AUTO PARTS | YH321761, YH321761C, YH321761P |
| AUTOPARTSOURCE | 593133 |
| AUTOXTRA | AX900920 |
| AUTOZONE | 72015, 72015DG |
| AutoZone | 72072DG, 72072DL |
| Autoxtra | AX900920P |
| BENDIX | PRT6063 |
| BOSCH | 25011461 |
| BRAKEBEST | 25011461, 580770FZN, 580770R, 580770RGS, 580770 |
| BREMBO | 09.D392.11 |
| BrakeBest | 521850RGS |
| Brembo | 09.B355.11, 09.B355.1X |
| CENTRIC | 120.62130, 121.62130, 126.62130CSL, 126.62130CSR, 126.62130SL, 126.62130SR, 127.62130L, 127.62130R, 128.62130L, 128.62130R, 227.62130L, 227.62130R, 320.62130, 321.62130, 120.6213, 320.6213 |
| Centric Parts | 120.62130, 121.62130, 126.62130CSL, 126.62130CSR, 126.62130SL, 126.62130SR, 127.62130L, 127.62130R, 128.62130L, 128.62130R, 227.62130L, 227.62130R, 320.62130, 321.62130 |
| DURA CORP | BR900920, BR90092002 |
| DuraGo | 900920, BR900920, BR90092002, BR900920-02 |
| GM | 13502045, 13502050, 13515905, 13515907, 13597459, 13597460, 23118274 |
| General Motors | 13502045, 13502050, 13515905, 13515907, 13597459, 13597460, 23118274 |
| MAGMA PRODUCTS | PSR223133 |
| NAPA BRAKES | SDK6280, SDK6836, TSR9012 |
| NEOTEK | 1072091GF |
| NEWTEK AUTOMOTIVE | 55185 |
| Newtek Automotive USA | 55185 |
| POWERSTOP | AR82148EVC |
| PROMAX | 14-55185 |
| PRONTO | BR900920 |
| Parts Master | 900920 |
| QUALIS | 41271 |
| TopNotch | TN580770GEO |
| UAP | 2900920, R62130 |
| WAGNER BRAKE | BD180439, BD180439E, R62130 |
| WINHERE | 6621035 |
| WORLDPAC | 1407-321761, 1427-731789 |
| Winhere | 6621850 |
RAYBESTOS 580770 Fits Vehicles
- Chevrolet Bolt EUV (2022-2023)
- Chevrolet Bolt EV (2017-2023)
- Chevrolet Cruze Limited (2016)
- Chevrolet Volt (2016-2019)
- Chevrolet Sonic (2012-2020)
- Chevrolet Cruze (2010-2019)
