(888) 312-8812 Login SignupMONROE 5530 OESpectrum Suspension Shock Absorber
Tap to view 3 more
$7749
Limited availability at this price!
In Stock
Get it by Thursday, Feb 19
MONROE 5530 Part Description
Manufacturer
Product Description
OESpectrum Suspension Shock Absorber
Features & Benefits
- REDUCED NOISE, VIBRATION AND HARSHNESS -- Twin Technology™ Active Control System delivers exceptional control under most driving conditions while isolating impact-related noise, vibration and harshness
- EXCEPTIONAL HANDLING -- Full displaced valving, tuned specifically to each vehicle, adjusts to road extremes while the larger bore provides more efficient damping control to provide consistency and a smooth ride
- CONTROL AND DURABILITY -- PTFE-banded piston provides consistent sealing between piston and pressure tube for better control and increased durability
- CONSISTENT RIDE -- OE all-weather fluid contains special additives to assist with extreme temperatures and help reduce oil breakdown
- IMPROVES PERFORMANCE -- Nitrogen gas-charge maintains tire-to-road contact for improved ride and handling by reducing aeration and shock fade
- BUILT TO LAST -- Self-lubricating fluid seal retains gas and reduces excessive friction against the piston rod to help reduce premature wear
- BUY WITH CONFIDENCE -- Comes with Monroe’s Limited Lifetime Warranty and exclusive Feel the Difference™ Guarantee
- BUY WITH CONFIDENCE -- Comes with Monroe's Limited Lifetime Warranty and exclusive Feel the DifferenceTM Guarantee
MONROE 5530 Specifications
Product Attributes
| Lower Mount Code | LS65 |
| Upper Mount Code | S1 |
| Dust Shield Included | No |
| Includes Bump Stop | No |
| Internal Rebound Bumper | Yes |
| Hydraulic Lockout | No |
| Part Description | Shock Absorber |
| Compressed Length | 16.89 IN |
| Extended Length | 26.46 in |
| Gas Charged | Yes |
| Lower Mount Type | Loop Bushing and Sleeve Mount - 1" Sleeve ID X 2" Sleeve OAL |
| Parts Pack(s) | P01682 |
| Travel Length | 9.37 in |
| Upper Mount Type | Stem Mount - Stem Length X M10 Thread Pitch |
| Compressed Length | 429 MM |
| Extended Length | 672.1 MM |
| Travel Length | 238 MM |
| Shock Absorber Rod End Measuring Point | Base of Stem |
| Shock Absorber Body End Measuring Point | Center of Loop |
| Lower Mount Type | Loop (Eyelet) Bushing and Sleeve |
| Lower Mount Code | LS65 |
| Upper Mount Type | Stem Mount - Stem Length X M10 Thread Pitch |
| Upper Mount Code | S1 |
| Mounting Hardware Included | Yes |
| Grade Type | Premium |
| Active or Passive Suspension | Passive |
| Adjustable Compression | No |
| Adjustable Rebound | No |
| Adjustable Ride Height | No |
Additional Information
| MSDS Sheet Number | 01170 |
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708803000 |
| Harmonized Tariff Code (Schedule B) | 8708800050 |
| Harmonized Tariff Code (HTS) | 8708801600 |
| UPC | 00048598179036 |
| VMRS Code | 016008003 |
| UNSPSC | 25172011 |
MONROE 5530 Cross References
| Brand | Part Number |
|---|---|
| Duralast | TS3239782B |
| GABRIEL | G511078 |
| KYB | 349219, 3440013 |
| KYB AMERICA LLC. | 3440013 |
| MasterPro Shocks and Struts | MZ108 |
| Mazda | KD3528910C, KD3528910D, KD3528910E, KD3534700A, KD3534900A |
| Monroe Shocks & Struts | 210012 |
| NAPA Shocks | 5530, NS5530 |
| OEM | KD3528910D |
| UNITY AUTOMOTIVE | 2-259190-001, 4-11695-259190-001, 4-11697-259190-001, 259190 |
MONROE 5530 Fits Vehicles
- Mazda CX-5 (2013-2014)
