(888) 312-8812 Login SignupWABCO 4235100470 Air Brake Chamber - Unistop Series, Disc Brakes
Tap to view 3 more
$14249
Limited availability at this price!
In Stock
Get as soon as Friday, Oct 30
WABCO 4235100470 Part Description
Manufacturer
Features & Benefits
- Heavy-duty steel housing resists impacts from road debris effectively
- Manual caging bolt supports emergency towing and vehicle recovery
- Designed specifically for compatible heavy-duty disc brake applications
- Helps prevent wheel lock during roadside recovery operations
WABCO Service Brake Chamber
The WABCO Service Brake Chamber incorporates a manual caging bolt that allows technicians to mechanically release the parking brake when compressed air is unavailable. Turning the caging bolt compresses the internal spring, allowing disabled vehicles to be moved or towed safely without restoring system air pressure first. This built-in manual release feature makes roadside recovery and workshop servicing more practical when pneumatic pressure cannot be supplied. Using the WABCO 4235100470 provides the emergency release capability expected for compatible heavy-duty brake systems.
WABCO 4235100470 Specifications
Product Attributes
| Total Length | 121.0 mm |
| Distance between bolts | 120.6 mm |
| Push-Rod Length | 15 mm |
| Bolt Lengths | 38.5 mm |
| Type Of Operation | Disc |
| Return-Spring Force | 190 N |
| Version | Without boot |
| Bolt Threads | M16 x 1.5 |
| Max. operating pressure | 10.2 bar |
| Temperature Range | -40°C to +80°C |
| Stroke | 65.0 mm |
| Push-rod thread | Ball R8 |
| Weight | 0.0022046 |
| Port threads | 3/8" - 18 NPTF |
| Type | 22 |
WABCO 4235100470 Cross References
| Brand | Part Number |
|---|---|
| VOLVO | 21897412 |
