MONROE 5528 Part Description
Manufacturer
Product Description
OESpectrum Suspension Shock Absorber
Features & Benefits
- REDUCED NOISE, VIBRATION AND HARSHNESS -- Twin Technology™ Active Control System delivers exceptional control under most driving conditions while isolating impact-related noise, vibration and harshness
- EXCEPTIONAL HANDLING -- Full displaced valving, tuned specifically to each vehicle, adjusts to road extremes while the larger bore provides more efficient damping control to provide consistency and a smooth ride
- CONTROL AND DURABILITY -- PTFE-banded piston provides consistent sealing between piston and pressure tube for better control and increased durability
- CONSISTENT RIDE -- OE all-weather fluid contains special additives to assist with extreme temperatures and help reduce oil breakdown
- IMPROVES PERFORMANCE -- Nitrogen gas-charge maintains tire-to-road contact for improved ride and handling by reducing aeration and shock fade
- BUILT TO LAST -- Self-lubricating fluid seal retains gas and reduces excessive friction against the piston rod to help reduce premature wear
- BUY WITH CONFIDENCE -- Comes with Monroe’s Limited Lifetime Warranty and exclusive Feel the Difference™ Guarantee
- BUY WITH CONFIDENCE -- Comes with Monroe's Limited Lifetime Warranty and exclusive Feel the DifferenceTM Guarantee
MONROE 5528 Specifications
Product Attributes
| Lower Mount Code | LS42 |
| Upper Mount Code | S1 |
| Dust Shield Included | No |
| Includes Bump Stop | No |
| Internal Rebound Bumper | Yes |
| Hydraulic Lockout | No |
| Part Description | Shock Absorber |
| Body Diameter | 1.75 IN |
| Compressed Length | 13.74 IN |
| Extended Length | 23.02 in |
| Gas Charged | Yes |
| Lower Mount Type | Loop Bushing and Sleeve Mount - 14MM Sleeve ID X 1.5/16" Sleeve OAL |
| Parts Pack(s) | P01505 |
| Travel Length | 9.28 in |
| Upper Mount Type | Stem Mount - Stem Length X M10 Thread Pitch |
| Compressed Length | 349 MM |
| Extended Length | 584.7 MM |
| Travel Length | 235.7 MM |
| Shock Absorber Rod End Measuring Point | Base of Stem |
| Shock Absorber Body End Measuring Point | Center of Loop |
| Body Diameter | 44.4 MM |
| Lower Mount Type | Loop (Eyelet) Bushing and Sleeve |
| Lower Mount Code | LS42 |
| Upper Mount Type | Stem Mount - Stem Length X M10 Thread Pitch |
| Upper Mount Code | S1 |
| Mounting Hardware Included | Yes |
| Grade Type | Premium |
| Active or Passive Suspension | Passive |
| Adjustable Compression | No |
| Adjustable Rebound | No |
| Adjustable Ride Height | No |
Additional Information
| MSDS Sheet Number | 01170 |
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708803000 |
| Harmonized Tariff Code (Schedule B) | 8708800050 |
| Harmonized Tariff Code (HTS) | 8708801600 |
| UPC | 00048598178954 |
| VMRS Code | 016008003 |
| UNSPSC | 25172011 |
MONROE 5528 Cross References
| Brand | Part Number |
|---|---|
| Duralast | TS3239752B |
| FCS | 346173 |
| FCS AUTO PARTS | 346173 |
| GABRIEL | G51799 |
| KYB | 3430024, 349109, 344459 |
| KYB AMERICA LLC. | 349109 |
| MasterPro Shocks and Struts | VW106 |
| Monroe Shocks & Struts | 210010 |
| NAPA Shocks | 5528, NS5528 |
| OEM | 5C0513025J, 5C0513029B, 5C0513029E, 5C0513029AJ |
| Top Quality | 785528 |
| Volkswagen | 5C0413031AQ, 5C0413031BB, 5C0413031DJ, 5C0413031DP, 5C0413031M, 5C0513025J, 5C0513029AJ, 5C0513029B, 5C0513029C, 5C0513029E |
MONROE 5528 Fits Vehicles
- Volkswagen Jetta (2012-2018)
