Raybestos 681939R - Raybestos R-Line Brake Rotor
$5299
MSRP: $70.02
Save: $17.03
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
RAYBESTOS part description
Product Description
Raybestos R-Line Brake Rotor
Application Summary
2020-2015 Ford Transit-250 Rear, 2020-2015 Ford Transit-350 Rear, 2020-2015 Ford Transit-150 Rear
Product Attributes
| ABS Tone Ring Included | No |
| Bolt Thread Pitch | 0.049 IN |
| Bolt Thread Pitch | 1.25 MM |
| Center Hole Diameter | 4.8 IN |
| Center Hole Diameter | 121.9 MM |
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
| Directional or Non-Directional Brake Surface | Non-Directional |
| Discard Thickness | 0.59 IN |
| Discard Thickness | 15 MM |
| Harmonize Code | 8708.30.5030 |
| Inside Diameter | 7.874 IN |
| Inside Diameter | 200 MM |
| Material | Cast Iron |
| Mounting Bolt Hole Circle Diameter | 5.906 IN |
| Mounting Bolt Hole Circle Diameter | 150 MM |
| Mounting Bolt Hole Diameter | 0.472 IN |
| Mounting Bolt Hole Diameter | 12 MM |
| Mounting Bolt Hole Quantity | 5 |
| Nominal Thickness | 0.71 IN |
| Nominal Thickness | 18.05 MM |
| Outside Diameter | 12.126 IN |
| Outside Diameter | 308 MM |
| Overall Height | 1.008 IN |
| Overall Height | 25.6 MM |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Solid |
| Stud/Lug Hole Quantity | 5 |
| Surface Type | Smooth |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | CN |
| UPC | 00887213190182 |
Part Interchanges
- Ford CK4Z2C026
- Ford CK4Z2C026C
- Wagner Brake BD180665
- PowerStop AR85175EVC
- BrakeBest 681939
- BrakeBest 681939R
- Centric Parts 120.65145
- Centric Parts 121.65145
- Centric Parts 320.65145
- Centric Parts 320.65145F
- AutoZone 75035DG
- Advance Auto Parts G15632SD
- Advance Auto Parts YH527279
- Advance Auto Parts YH527279C
- Autoxtra AX901368
- Dura Corp BR901368
- Newtek Automotive USA R1368
- Promax 14-640003
- Motorcraft BRRC8
- Wagner Brake BD180665E
- Ford KU2Z2V026E
- Dynamic Friction Company 600-54228
- BrakeBest 670126RGS
- AutoZone 75034
- AutoZone 75034DG
- AutoZone 75034DL
- DuraGo BR901368
- AutoZone 75042DG
- AutoZone 75042DL
- Ford CK4Z2C026E
- Qualis 42310
- Advance Auto Parts YH527279P
RAYBESTOS 681939R Cross Reference
We have 18 alternatives for the 681939R by RAYBESTOS:
- FORD CK4Z2C026
- FORD CK4Z2C026C
- ADVANCE AUTO PARTS G15632SD
- ADVANCE AUTO PARTS YH527279
- ADVANCE AUTO PARTS YH527279C
- AUTOXTRA AX901368
- AUTOZONE 75035DG
- BRAKEBEST 681939
- BRAKEBEST 681939R
- CENTRIC 120.65145
- CENTRIC 121.65145
- CENTRIC 320.65145
- CENTRIC 320.65145F
- DURA CORP BR901368
- NEWTEK AUTOMOTIVE R1368
- POWERSTOP AR85175EVC
- PROMAX 14-640003
- WAGNER BRAKE BD180665
Fits Vehicles
- Ford Transit-250 (2015-2023)
- Ford Transit-350 (2015-2023)
- Ford Transit-150 (2015-2023)
