RAYBESTOS 580712FZN - Brake Parts Inc Raybestos Element3 Coated Disc Brake Rotor
$15149
MSRP: $166.78
Save: $15.29
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
RAYBESTOS part description
California Proposition 65 Warning
California Proposition 65 Warning
WARNING: This product can expose you to chemical which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information, go to www.P65Warnings.ca.gov. (Read more)
Product Description
Raybestos Element3 Coated Brake Rotor
Application Summary
2022-2017,2015-2010 Chevrolet Camaro Rear, 2019-2009 Cadillac CTS Rear
Product Attributes
| ABS Tone Ring Included | No |
| Center Hole Diameter | 2.653 IN |
| Center Hole Diameter | 67.4 MM |
| 9565 | Drum-In-Hat |
| Discard Thickness | 1.024 IN |
| Discard Thickness | 26 MM |
| Harmonize Code | 8708.30.5030 |
| Inside Diameter | 9.957 IN |
| Inside Diameter | 252.9 MM |
| Mounting Bolt Hole Circle Diameter | 4.724 IN |
| Mounting Bolt Hole Circle Diameter | 120 MM |
| Mounting Bolt Hole Diameter | 0.647 IN |
| Mounting Bolt Hole Diameter | 16.45 MM |
| Mounting Bolt Hole Quantity | 5 |
| Nominal Thickness | 1.107 IN |
| Nominal Thickness | 28.1 MM |
| Outside Diameter | 14.368 IN |
| Outside Diameter | 364.95 MM |
| Overall Height | 1.87 IN |
| Overall Height | 47.5 MM |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Vented |
| Stud/Lug Hole Quantity | 5 |
| Surface Type | Smooth |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | CN |
| UPC | 00887213144727 |
Part Interchanges
- General Motors 22798839
- General Motors 23304410
- General Motors 23369743
- General Motors 25851166
- General Motors 92223366
- General Motors 92245929
- Wagner Brake BD180299
- Bendix PRT5901
- BrakeBest 580712
- BrakeBest 580712FZN
- BrakeBest 580712R
- BrakeBest 580712RGS
- Centric Parts 121.62119
- Centric Parts 125.62119
- Centric Parts 125.62119CRY
- Centric Parts 126.62119CSL
- Centric Parts 126.62119CSR
- Centric Parts 126.62119SL
- Centric Parts 126.62119SR
- Centric Parts 127.62119CL
- Centric Parts 127.62119CR
- Centric Parts 127.62119L
- Centric Parts 127.62119R
- Centric Parts 128.62119CL
- Centric Parts 128.62119CR
- Centric Parts 128.62119L
- Centric Parts 128.62119R
- Centric Parts 227.62119L
- Centric Parts 227.62119R
- Centric Parts 320.62119C
- AutoZone 41251
- AutoZone 41251DG
- AutoZone 72080DL
- Advance Auto Parts YH275230P
- Autoxtra AX900746
- Dura Corp BR55163
- Dura Corp BR900746
- Winhere 6621097
- Newtek Automotive USA 55163
- Promax 14-55163
- UAP 2900746
- UAP R62119
- Wagner Brake BD180299E
- Wagner Brake BD180725E
- Centric Parts 120.62119
- Centric Parts 320.62119H
- DuraGo 900746
- DuraGo BR900746
RAYBESTOS 580712FZN Cross Reference
We have 44 alternatives for the 580712FZN by RAYBESTOS:
- BENDIX PRT5901
- GM 22798839
- GM 23304410
- GM 23369743
- GM 25851166
- GM 92223366
- GM 92245929
- ADVANCE AUTO PARTS YH275230P
- AUTOXTRA AX900746
- AUTOZONE 41251
- AUTOZONE 41251DG
- AUTOZONE 72080DL
- BRAKEBEST 580712
- BRAKEBEST 580712FZN
- BRAKEBEST 580712R
- BRAKEBEST 580712RGS
- CENTRIC 120.62119
- CENTRIC 121.62119
- CENTRIC 125.62119
- CENTRIC 125.62119CRY
- CENTRIC 126.62119CSL
- CENTRIC 126.62119CSR
- CENTRIC 126.62119SL
- CENTRIC 126.62119SR
- CENTRIC 127.62119CL
- CENTRIC 127.62119CR
- CENTRIC 127.62119L
- CENTRIC 127.62119R
- CENTRIC 128.62119CL
- CENTRIC 128.62119CR
- CENTRIC 128.62119L
- CENTRIC 128.62119R
- CENTRIC 227.62119L
- CENTRIC 227.62119R
- CENTRIC 320.62119C
- CENTRIC 320.62119H
- DURA CORP BR55163
- DURA CORP BR900746
- NEWTEK AUTOMOTIVE 55163
- PROMAX 14-55163
- UAP 2900746
- UAP R62119
- WAGNER BRAKE BD180299
- WINHERE 6621097
Fits Vehicles
- Chevrolet Camaro (2010-2015, 2017-2022)
- Cadillac CTS (2009-2019)
