RAYBESTOS 580263R Raybestos R-Line Brake Rotor

★★★★★ (0)

$153.61

MSRP Pricing shown.

Out of Stock

We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.

We may have similar parts for sale. Search Alternatives >

RAYBESTOS 580263R Part Description

Manufacturer

RAYBESTOS

Product Description

Raybestos R-Line Brake Rotor

Application Summary

2018-1999 Blue Bird All American FE Front, 2018-2005 Hino 268 Front, 2018-2005 Hino 268 Rear, 2018-2004 Blue Bird Vision School Bus Front, 2009-2003 GMC C5500 Topkick Front, 2009-2003 GMC C5500 Topkick Rear, 2017-2006 Hino 258 Front

Features & Benefits

  • OE Fit, Form, and Function
  • Developed from OE samples and made with G3000-qualified material, ensuring OE fit, form and function for dependable braking.
  • SAE Standard
  • R-Line Rotors meet the SAE standard for tensile strength, providing structural integrity and a maximum service life.
  • Low Initial Lateral Runout and Thickness Variation
  • R-Line Rotors have a small parameter lateral runout and a thickness variation ensuring less pedal pulsation, less brake noise, and an extended pad life.
  • Mill Balanced Edges
  • R-Line Rotors are mill balanced and 100 percent validated. This helps minimize the thickness variation on the rotor and leads to minimized vibration and smoother stopping.

RAYBESTOS 580263R Specifications

Product Attributes

ABS Tone Ring IncludedYes
Center Hole Diameter6 IN
Center Hole Diameter152.4 MM
Conventional Or Drum-In-Hat Type RotorConventional
Discard Thickness1.419 IN
Discard Thickness36.05 MM
Harmonize Code8708.30.5030
Mounting Bolt Hole Circle Diameter7.25 IN
Mounting Bolt Hole Circle Diameter184.15 MM
Mounting Bolt Hole Quantity10
Nominal Thickness1.541 IN
Nominal Thickness39.15 MM
Outside Diameter15.376 IN
Outside Diameter390.55 MM
Overall Height3.403 IN
Overall Height86.45 MM
Salability RestrictionsNo
Solid Or Vented Type RotorVented
Stud/Lug Hole Quantity10
UNSPSC Code25171715

Additional Information

Country of Origin (Primary)CN
Canadian Harmonizing Tariff Code8708309990
Harmonized Tariff Code (HTS)8708305030
UPC00887213286229

RAYBESTOS 580263R Cross References

BrandPart Number
ACDELCO177-0960
AUTOXTRAAX900906
Advance Auto PartsYH145688
BRAKEBEST580263, 580263RGS
CENTRIC120.80014, 120.80014CRY, 121.80014, 320.80014, 120.80015, 121.80015
Casting Numbers211657-C
Centric Parts120.80014, 120.80014CRY, 121.80014, 320.80014
DAYTON WALTHER23-123557-004
DURA CORPBR55104, BR900906
DuraGo900906, BR900906
EUCLIDE-12524
FORMULA BLUE HYDRAULIC BRAKE PARTSE12585019
GM10356593, 10356608, 15952914, 88936204
General Motors10356593, 10356608, 15952914, 88936204
HINO23123557004
INTERNATIONAL HARVESTER (IHC)PFH39008620
MAGMA PRODUCTSPMR227302
MERITOR23-123557-004, 23123557009
NEWTEK AUTOMOTIVE55104
Newtek Automotive USA55104
PERFORMANCE FRICTION390.086.20
PROMAX14-55104
Qualis41224
UAP55104
WAGNERBD126363
WAGNER BRAKEBD126363
WEBB54775P-65
WINHERE6621304

RAYBESTOS 580263R Fits Vehicles

  • Freightliner FL50 (1998-2005)
  • Freightliner FL60 (1998-2005)
  • Freightliner FL70 (1998-2005)
  • Blue Bird All American FE (1999-2018)
  • Blue Bird SHL TC2000 (1993-2003)
  • Blue Bird TC1000 (1997-2000)
  • Blue Bird TC2000 (1989-2004)
  • Blue Bird Vision School Bus (2004-2018)
  • Chevrolet C4500 Kodiak (2003-2009)
  • Chevrolet C5500 Kodiak (2003-2009)
  • Chevrolet C6500 Kodiak (2003-2009)
  • Chevrolet C7500 Kodiak (2003-2009)
  • Chevrolet T6500 (2004-2009)
  • Chevrolet T7500 (2004-2009)
  • Chevrolet T8500 (2004-2009)
  • Fleetwood Bounder (2010)
  • GMC C4500 Topkick (2003-2009)
  • GMC C5500 Topkick (2003-2009)
  • GMC C6500 Topkick (2003-2009)
  • GMC C7500 Topkick (2003-2009)
  • GMC T6500 (2004-2009)
  • GMC T7500 (2004-2009)
  • Hino 238 (2005-2014)
  • Hino 258 (2006-2017)
  • Hino 258LP (2006-2020)
  • Hino 268 (2005-2020)
  • Hino 308 (2005-2008)
  • Isuzu FTR (2003-2011)
  • Isuzu FVR (2003-2011)
  • Isuzu FXR (2004-2011)
  • Isuzu HTR (2005-2008)
  • Isuzu HVR (2005-2008)
  • Workhorse Custom Chassis R26 (2007-2008)
  • Workhorse Custom Chassis W24 (2004-2005, 2007-2009, 2011)
  • Workhorse Custom Chassis W62 (2007-2012)
  • Workhorse R26 (2007-2009)
  • Workhorse W24 (2004-2009)
  • Workhorse W25 (2005-2009)
  • Workhorse W62 (2007-2011)
