RAYBESTOS 780995 Part Description
Manufacturer
Product Description
Raybestos Specialty - Street Performance Brake Rotor
Application Summary
2017-2015 Chrysler 200 Front, 2016-2013 Dodge Dart Front
Features & Benefits
- Application Specific Enhanced Iron
- Raybestos® Performance Rotors are made with enhanced iron which suppresses noise and keeps brakes running cool, quiet and vibration free.
- Raybestos(R) Performance Rotors are made with enhanced iron which suppresses noise and keeps brakes running cool, quiet and vibration free.
- Cooling Vanes
- The cooling vanes match OE configurations and provide optimal cooling and reduced fade.
- Application Specific Coating
- Depending on the application, Performance Rotors will have one of the following finishes: Black fusion coating on the rotor hat Grey Fusion 4.0® coating on the entire rotor
- Depending on the application, Performance Rotors will have one of the following finishes: Black fusion coating on the rotor hat Grey Fusion 4.0(R) coating on the entire rotor
- Black fusion coating on the rotor hat and Grey Fusion 4.0® coating on the rotor inboard surface and cooling vanes
- Black fusion coating on the rotor hat and Grey Fusion 4.0(R) coating on the rotor inboard surface and cooling vanes
- Turned Finish
- Turned finish minimizes noise and improves responsiveness for smoother stops.
- S-Groove Slot
- Depending on the application, some Raybestos® Performance Rotors are designed with a patented S-Groove Slot.
- Depending on the application, some Raybestos(R) Performance Rotors are designed with a patented S-Groove Slot.
RAYBESTOS 780995 Specifications
Product Attributes
| ABS Tone Ring Included | No |
| Center Hole Diameter | 2.76 IN |
| Center Hole Diameter | 70.1 MM |
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
| Directional or Non-Directional Brake Surface | Non-Directional |
| Discard Thickness | 1.024 IN |
| Discard Thickness | 26 MM |
| Harmonize Code | 8708.30.5030 |
| Inside Diameter | 7.028 IN |
| Inside Diameter | 178.5 MM |
| Material | Cast Iron |
| Mounting Bolt Hole Circle Diameter | 4.331 IN |
| Mounting Bolt Hole Circle Diameter | 110 MM |
| Mounting Bolt Hole Diameter | 0.65 IN |
| Mounting Bolt Hole Diameter | 16.5 MM |
| Mounting Bolt Hole Quantity | 5 |
| Nominal Thickness | 1.102 IN |
| Nominal Thickness | 28 MM |
| Outside Diameter | 12.008 IN |
| Outside Diameter | 305 MM |
| Overall Height | 1.56 IN |
| Overall Height | 39.6 MM |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Vented |
| Stud/Lug Hole Quantity | 5 |
| Surface Type | Smooth |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708309990 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00887213136890 |
RAYBESTOS 780995 Cross References
| Brand | Part Number |
|---|---|
| ADVANCE AUTO PARTS | YH425687, YH425687C, YH425687P |
| AUTOXTRA | AX901198 |
| AUTOZONE | 72120, 72120DG, 72120DL |
| Autoxtra | AX901198P |
| BENDIX | PRT6179 |
| BRAKEBEST | 780995, 780995FZN, 780995R |
| BrakeBest | 780995RGS |
| Brembo | 09.9363.2X, 09.9363.21, 09.9363.2S |
| CENTRIC | 120.63080, 120.63080CRY, 121.63080, 126.63080CSL, 126.63080CSR, 126.63080SL, 126.63080SR, 127.63080L, 127.63080R, 128.63080CL, 128.63080CR, 128.63080L, 128.63080R, 320.63080, 120.6308, 320.6308 |
| CHRYSLER | 68082120AA, 68242624AA, 68257206AA |
| Centric Parts | 120.63080, 120.63080CRY, 121.63080, 126.63080CSL, 126.63080CSR, 126.63080SL, 126.63080SR, 127.63080L, 127.63080R, 128.63080CL, 128.63080CR, 128.63080L, 128.63080R, 320.63080 |
| DURA CORP | BR901198, BR9011198 |
| DuraGo | BR901198, BR901394 |
| Dynamic Friction Company | 600-39025 |
| Eurorotor | 51204 |
| MAGMA PRODUCTS | PSR143077 |
| NEOTEK | 1070114GF |
| NEWTEK AUTOMOTIVE | 53071 |
| Newtek Automotive USA | 53071 |
| POWERSTOP | AR83086EVC |
| PROMAX | 14-53071, 14-HR013 |
| PRONTO | BR901198 |
| Qualis | 43183 |
| TopNotch | TN780995GEO |
| UAP | R63080 |
| Ultra Brake | 51204 |
| WAGNER BRAKE | BD180551 |
| WORLDPAC | 1407-425687, 1427-731813 |
| WORLDPARTS | WS1-153071 |
| Wagner Brake | BD180551E |
| Winhere | 6621252, 6621430 |
RAYBESTOS 780995 Fits Vehicles
- Chrysler 200 (2015-2017)
- Dodge Dart (2013-2016)
