(888) 312-8812 Login SignupCENTRIC 121.63080 C-Tek Standard Brake Rotor
Tap to view 4 more
Out of Stock
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
CENTRIC 121.63080 Part Description
Manufacturer
Product Description
C-Tek Standard Brake Rotor
Features & Benefits
- Non-Directional Finishes. Machined non-friction surfaces. Widest application coverage in the aftermarket
- For heat capacity and strength
- OE Vane Design & Plate Thickness
- Optimal Surface Finish
- For consistent stopping power
- Low Initial Lateral Run-Out and Disc-Thickness Variation
- For smooth, vibration free stopping
- Precision Balanced
- For vibration free performance
CENTRIC 121.63080 Specifications
Product Attributes
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Weight [cntrc] Kgs | 7.960 |
| Vane Style [cntrc] | Pillar |
| Hat Id [cntrc] In | 5.362 |
| Product Grade [cntrc] | Standard |
| Disc Mounting [cntrc] | Floating |
| Hat Id [cntrc] Mm | 136.200 |
| Misc Holes [cntrc] | 5 |
| Weight [cntrc] Lbs | 17.550 |
| Discard Thickness | 26.000 MM |
| Discard Thickness | 1.024 IN |
| Nominal Thickness | 1.102 IN |
| Nominal Thickness | 28.000 MM |
| Overall Height | 1.575 IN |
| Overall Height | 40.000 MM |
| Outside Diameter | 305.000 MM |
| Outside Diameter | 12.008 IN |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Bearings Included | No |
| Center Hole Diameter | 70.000 MM |
| Center Hole Diameter | 2.756 IN |
| Mounting Bolt Hole Circle Diameter | 110.000 MM |
| Mounting Bolt Hole Circle Diameter | 4.331 IN |
| Stud/Lug Hole Quantity | 5 |
| Stud/Lug Hole Diameter | 0.654 IN |
| Stud/Lug Hole Diameter | 16.600 MM |
| Hat Finish | Bare |
Additional Information
| Harmonized Tariff Code (HTS) | 8708305030 |
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 00805890945246 |
CENTRIC 121.63080 Cross References
CENTRIC 121.63080 Fits Vehicles
- Dodge Dart (2013-2016)
- Jeep Compass (2017-2022)
- Jeep Renegade (2015-2022)
- Chrysler 200 (2015-2017)
- Fiat 500X (2016-2022)
