(888) 312-8812 Login SignupRAYBESTOS 781769 Raybestos Specialty - Street Performance Brake Rotor
$49.68
MSRP Pricing shown.
Out of Stock
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
RAYBESTOS 781769 Part Description
Manufacturer
Product Description
Raybestos Specialty - Street Performance Brake Rotor
Application Summary
2020-2014 Fiat 500L Rear
Features & Benefits
- Application Specific Enhanced Iron
- Raybestos® Performance Rotors are made with enhanced iron which suppresses noise and keeps brakes running cool, quiet and vibration free.
- Raybestos(R) Performance Rotors are made with enhanced iron which suppresses noise and keeps brakes running cool, quiet and vibration free.
- Cooling Vanes
- The cooling vanes match OE configurations and provide optimal cooling and reduced fade.
- Application Specific Coating
- Depending on the application, Performance Rotors will have one of the following finishes: Black fusion coating on the rotor hat Grey Fusion 4.0® coating on the entire rotor
- Depending on the application, Performance Rotors will have one of the following finishes: Black fusion coating on the rotor hat Grey Fusion 4.0(R) coating on the entire rotor
- Black fusion coating on the rotor hat and Grey Fusion 4.0® coating on the rotor inboard surface and cooling vanes
- Black fusion coating on the rotor hat and Grey Fusion 4.0(R) coating on the rotor inboard surface and cooling vanes
- Turned Finish
- Turned finish minimizes noise and improves responsiveness for smoother stops.
- S-Groove Slot
- Depending on the application, some Raybestos® Performance Rotors are designed with a patented S-Groove Slot.
- Depending on the application, some Raybestos(R) Performance Rotors are designed with a patented S-Groove Slot.
RAYBESTOS 781769 Specifications
Product Attributes
| ABS Tone Ring Included | No |
| Center Hole Diameter | 2.324 IN |
| Center Hole Diameter | 59 MM |
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
| Discard Thickness | 0.315 IN |
| Discard Thickness | 8 MM |
| Harmonize Code | 8708.30.5030 |
| Inside Diameter | 6.87 IN |
| Inside Diameter | 174.5 MM |
| Mounting Bolt Hole Circle Diameter | 3.858 IN |
| Mounting Bolt Hole Circle Diameter | 98 MM |
| Mounting Bolt Hole Diameter | 0.516 IN |
| Mounting Bolt Hole Diameter | 13.1 MM |
| Mounting Bolt Hole Quantity | 5 |
| Nominal Thickness | 0.394 IN |
| Nominal Thickness | 10 MM |
| Outside Diameter | 10.394 IN |
| Outside Diameter | 264 MM |
| Overall Height | 1.594 IN |
| Overall Height | 40.5 MM |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Solid |
| Stud/Lug Hole Quantity | 5 |
| Surface Type | Smooth |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708309990 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00887213137064 |
RAYBESTOS 781769 Cross References
| Brand | Part Number |
|---|---|
| ADVANCE AUTO PARTS | YH507463, YH507463C, YH507463P |
| AutoZone | 72131DL |
| BRAKEBEST | 781769, 781769FZN, 781769R, 912074RGS |
| CENTRIC | 120.04003, 121.04003, 126.04003SL, 126.04003SR, 127.04003L, 127.04003R, 128.04003L, 128.04003R, 320.04003 |
| Centric Parts | 120.04003, 121.04003, 126.04003SL, 126.04003SR, 127.04003L, 127.04003R, 128.04003L, 128.04003R, 320.04003 |
| DURA CORP | BR901328 |
| DuraGo | BR901328 |
| FIAT | 51914664, 52026319, 52026321, 68201271AA |
| MAGMA PRODUCTS | PSR143081 |
| NEWTEK AUTOMOTIVE | R1328 |
| Newtek Automotive USA | R1328 |
| POWERSTOP | EBR1423EVC |
| PROMAX | 14-620001 |
| Qualis | 45636 |
| UAP | 2901328 |
| WORLDPAC | 1407-507463, 1427-719591 |
| Wagner Brake | BD180714E |
| Winhere | 6612074 |
RAYBESTOS 781769 Fits Vehicles
- Fiat 500L (2014-2020)
