Centric 120.65149 - Centric Premium Brake Rotor
$5799
MSRP: $139.55
Save: $81.56
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
CENTRIC part description
Product Description
Centric Premium Brake Rotor
Features & Benefits
- Symmetric vane; split-core castings for uniform heat distribution. Black E-Coat anti-corrosive coating protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life
Product Attributes
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Weight [cntrc] Kgs | 8.980 |
| Product Grade [cntrc] | Premium |
| Misc Holes [cntrc] | 0 |
| Weight [cntrc] Lbs | 19.750 |
| Disc Mounting [cntrc] | Floating |
| Hat Id [cntrc] Mm | 205.600 |
| OEM Vane Count [cntrc] | 50 |
| Vane Style [cntrc] | Straight |
| Hat Id [cntrc] In | 8.094 |
| Discard Thickness | 0.787 IN |
| Discard Thickness | 20.000 MM |
| Nominal Thickness | 22.000 MM |
| Nominal Thickness | 0.866 IN |
| Hat Finish | Coated |
| Overall Height | 44.900 MM |
| Overall Height | 1.768 IN |
| Outside Diameter | 336.000 MM |
| Outside Diameter | 13.228 IN |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Bearings Included | No |
| Center Hole Diameter | 3.543 IN |
| Center Hole Diameter | 90.000 MM |
| Mounting Bolt Hole Circle Diameter | 135.000 MM |
| Mounting Bolt Hole Circle Diameter | 5.315 IN |
| Stud/Lug Hole Quantity | 5 |
| Stud/Lug Hole Diameter | 0.614 IN |
| Stud/Lug Hole Diameter | 15.600 MM |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 805890409540 |
Part Interchanges
CENTRIC 120.65149 Cross Reference
We have 4 alternatives for the 120.65149 by CENTRIC:
Fits Vehicles
- Ford F-150 (2015-2017)
