(888) 312-8812 Login SignupHORTON 99A4701 Engine Cooling Fan Clutch
Tap to view 3 more
MSRP: $3,655.08
$1,31549
Save $2,339.59
Limited availability at this price!
In Stock
Get it by Thursday, Jul 2
HORTON 99A4701 Part Description
Manufacturer
Product Description
Engine Cooling Fan Clutch
Application Summary
INTERNATIONAL
Features & Benefits
- Replaces 994922. This is a Clutch Pack Only, requires additional Pulley and Journal Bracket Assemblies for complete fan drive replacement.
Two-speed fan clutch, fan clutch, engine cooling, fan drive, performance, cooling system, horsepower, performance
HORTON 99A4701 Specifications
Product Attributes
| BOLT CIRCLE | 6 IN |
| CLUTCH PACK MTG BOLT DIAMETER | 7.15 IN |
| CLUTCH PACK MTG BOLT ORIENTATION | 4 -M8 x 1.25 Mtg Studs @ 90° |
| CLUTCH PACK PILOT DIAMETER | 5.75 IN |
| FAN PILOT DIAMETER | 5 IN |
| Heavy Duty | 0 |
| MTG STUD LENGTH | 1.1 IN |
| MTG STUD THREAD TYPE | .312-18 UNC |
| Stud Thread Size | .312-18 IN |
| BELT CONFIGURATION | - |
| BACK PULLEY DIAMETER | - |
| Center of JB To Top Right Mounting Hole | - |
| HORIZONTAL MOUNTING DISTANCE | - |
| VERTICAL MOUNTING DISTANCE | - |
| Fan Bolt Circle | - |
| FRONT PULLEY DIAMETER | - |
Additional Information
| Country of Origin (Primary) | US |
| Harmonized Tariff Code (Schedule B) | 8483604040 |
| Harmonized Tariff Code (HTS) | 8483604040 |
| NAFTA Preference Criterion Code | B |
| OEM's Part Number | 98A4701 |
| Warranty Distance | 300000 |
| Warranty Distance UOM | DH |
| Warranty Special | 7500 Hours |
| Warranty Special UOM | TX |
| Warranty Time | 36 |
| Warranty Time UOM | MO |
| VMRS Code | 042003131 |
HORTON 99A4701 Cross References
| Brand | Part Number |
|---|---|
| G2MZ1104AD, HOR99A4701 | |
| Freightliner | HOR 99A4701 |
| Horton | 79A7701, 98A4701 |
| MCI | HOR99A4701 |
| Mack | 3912-99A4701 |
| NAVISTAR | FLT244700, FLT24256 |
| NAVISTARPFC | FLT24256, FLT244700 |
| Navistar | 2588342C91, 3593720C92, HOR99A4701 |
| Paccar Parts | 99A4701H0R |
