GATES G30102-0606 - Hyd Coupling/Adapter- Air Brake to Male Pipe - 45 (Copper Tubing Compression)
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
Sometimes we may have similar parts for sale, click the button below to see if anything matches.
GATES part description
California Proposition 65 Warning
WARNING: This product can expose you to chemical which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information, go to www.P65Warnings.ca.gov. (Read more)
Product Description
Air Brake to Male Pipe - 45 (Copper Tubing Compression)
Features & Benefits
- Used with copper tubing in air brake systems
- Easy to assemble - no flaring tools required
- Versatile - can be used with nylon tubing by replacing the long nut and sleeve with an insert, rigid sleeve and nut
- Meets DOT FMVSS 571.106, SAE J246 and SAE J1131 requirements
- Temperature Range: -65 Deg. F to +250 Deg. F (-53 Deg. C to +121 Deg. C)
Product Attributes
Coupling Description | Copper Tubing Compression Air Brake to Male Pipe - 45 |
Industrial Description | 6ABCTC-6MP45 |
Thread Size | 17/32-24 |
Outside Diameter | .375 IN |
Maximum Working Pressure | 150 PS |
Temperature Rating | -60 Deg. F to +250 Deg. F (-53 Deg. C to +121 Deg. C) |
Material | 360 Brass |
Additional Information
Country of Origin (Primary) | US |
Harmonized Tariff Code (Schedule B) | 7412200015 |
UPC | 00029769148600 |
VMRS Code | 059032033 |
UNSPSC | 27121700 |
