(888) 312-8812 Login SignupDELPHI AF10152 Mass Air Flow Sensor
MSRP: $326.32
$25699
Save $69.33
Limited availability at this price!
In Stock
Get it by Wednesday, Feb 4
DELPHI AF10152 Part Description
Manufacturer
Product Description
Mass Air Flow Sensor
Features & Benefits
- Delphi mass air flow sensors are the global benchmark for accuracy and signal noise
- Delphi mass air flow sensors feature high quality sensing elements for outstanding performance over a wide range of ambient temperatures
- Delphi is a manufacturer of OE mass air flow sensors since their first use over 30 years ago
- All parts are calibrated and tested to match the OE part
- Probe solution offered wherever possible to reduce repair time by eliminating the need to replace the flow tube
- Delphi OE technology validated to match the vehicle applications
DELPHI AF10152 Specifications
Product Attributes
| Item Grade | Premium |
| Package Contents | Mass Air Flow Sensor - Probe Only |
| Color | Black and Silver |
| Housing Included | No |
| Terminal Type | Blade |
| Mounting Hardware Included | No |
| Universal Or Specific Fit | Specific |
| Grade Type | Standard Replacement |
| Connector Quantity | 1 |
| Connector Shape | Rectangle |
| Mounting Hole Quantity | 2 |
| Terminal Quantity | 3 |
| Connector Gender | Female |
| Terminal Gender | Male |
| Wiring Harness Included | No |
| Mounting Type | Bolt-On |
| Mounting Bracket Included | No |
| Sensor Casing Length | 84 MM |
| Sensor Casing Width | 49.5 MM |
| Voltage | 12.0 2H |
| Gasket Or Seal Included | Yes |
| Bolt Hole Center To Bolt Hole Center | 62.70 MM |
| Mounting Hole Diameter | 4.5 MM |
| Seal Outside Diameter | 25 mm |
| Seal Quantity | 1 |
| Sensor Casing Length | 3.3 IN |
| Sensor Casing Width | 1.9 IN |
| Bolt Hole Center To Bolt Hole Center | 2.40 IN |
| Mounting Hole Diameter | 0.1 IN |
| Seal Outside Diameter | 0.9 IN |
| Intake Air Temperature (IAT) Included | No |
Additional Information
| Warranty Distance UOM | DH |
| Warranty Distance | 12000 |
| Harmonized Tariff Code (Schedule B) | 9026800000 |
| Warranty Time UOM | MO |
| Warranty Time | 12 |
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (HTS) | 9026802000 |
| UPC | 00689604215913 |
| VMRS Code | 045021019 |
| UNSPSC | 41111931 |
DELPHI AF10152 Cross References
| Brand | Part Number |
|---|---|
| ACDelco | 2133565 |
| Airtex | 5S2717 |
| Autopart International | 228378 |
| BWD | 221070M, MA1044 |
| Beck/Arnley | 157-0355 |
| Blue Streak Electronics New | MF21070N |
| BorgWarner | 221070M |
| CARDONE New | 86-9937, 8650037 |
| CARDONE Reman | 74-50037 |
| Carquest | MQ6288 |
| Datsun/Nissan | 22680-2J200 |
| Dorman | 917-915 |
| Duralast | DL-3009, DL-6108 |
| Echlin | MAF69937, XTP450037 |
| GLOBAL PARTS DISTRIBUTORS | 1813099 |
| HITACHI | MAF0024 |
| Hitachi Automotive | MAF0024, AFH70-14M |
| IMC | 128 38028 151 |
| N/A | 7450037, 869937, 226802J200, 12838028151, 1570355, 245-1156, 245-2156 |
| NAPA Reman Computers | MAF69937, XTP450037 |
| NGK SPARK PLUGS | MG0100 |
| NTK | MG0100 |
| Richporter | MA188, MA174 |
| STANDARD IGNITION | MAS0173 |
| Spectra Premium | MA174, MA275 |
| Standard Motor Products | MF21070, MAS0173 |
| VEMO | V38720005 |
| WAI | MAF10152 |
| WALKER PRODUCTS | 245-1156 |
| Wells | SU5065 |
DELPHI AF10152 Fits Vehicles
- INFINITI QX4 (1997)
- Nissan Pathfinder (1996-1997)
