(888) 312-8812 Login SignupDELPHI HP10141 Fuel Pump Hanger Assembly
MSRP: $207.78
$10099
Save $106.79
Limited availability at this price!
In Stock
Get it by Friday, Jul 24
DELPHI HP10141 Part Description
Manufacturer
Product Description
Fuel Pump Hanger Assembly
Features & Benefits
- Delphi is a global OE manufacturer and all fuel pumps are built to Delphi's OE standards
- Delphi pumps are designed to operate under extreme temperatures with quick engine starts
- Metal tubes in Delphi hangers are routed so as to not contact the tank at any point eliminating noise and vibration during vehicle operation
- Empty float height and float retention matches OE specifications and guarantees correct gas gauge reading
- Restores fast pressure performance and system integrity, translating to better pumping through less energy
- Lower failure rates due to its innovative design and durability
- Part is validated, tested and matched to the right vehicle application
- Lower amperage draws less load on vehicle's electrical system
- Always be sure to check and clean fuel tank to avoid unnecessary returns
DELPHI HP10141 Specifications
Product Attributes
| Item Grade | Standard Replacement |
| System Pressure | 36 psi |
| Fuel Level Sender Assembly Included | Yes |
| Package Contents | Fuel Pump Hanger Assembly w/Float Arm, Seal, Lock Ring, Instruction Sheet |
| Outlet Outside Diameter | 0.375 IN |
| Voltage | 12.0 2H |
| Fuel Type | Gas |
| Maximum Pressure | 80.0 PS |
| Terminal Type | Pin |
| Gasket Or Seal Included | Yes |
| Terminal Quantity | 4 |
| Terminal Gender | Male |
| Strainer Included | Yes |
| Inlet Type | Strainer |
| Outlet Type | Quick Connect |
| Outlet Quantity | 2 |
| In Tank or External | In Tank |
| Resistance Ohms Empty | 15.0 82 |
| Resistance Ohms Full | 160.0 82 |
| Internal Or External Strainer | External |
| Pump Type | Electric |
| Average Current Draw | 7.0 68 |
| Average Flow Rating | 24.0 GPH |
| Material | Metal |
| Fuel Sending Unit Included | Yes |
| Negative Ground | No |
| Mounting Hardware Included | No |
| Grade Type | Premium |
| Connector Shape | Oval |
| Lock Ring Included | Yes |
| Connector Gender | Female |
| Inlet Quantity | 1 |
| Fuel Pump Included | Yes |
| Gasket Or Seal Material | Nitrile Rubber |
| Minimum Pressure | 36 PS |
| Pump Design | Turbine |
| Fuel Tank Pressure Sensor Included | No |
| Universal Or Specific Fit | Specific |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8413309000 |
| Harmonized Tariff Code (HTS) | 9026102080 |
| Warranty Special | Limited Lifetime |
| Warranty Special UOM | LF |
| Country of Origin (Primary) | MX |
| UPC | 00689604215180 |
| VMRS Code | 044003257 |
| UNSPSC | 40151532 |
DELPHI HP10141 Cross References
| Brand | Part Number |
|---|---|
| Airtex | E2002, E2078S |
| AutoZone | DHP10141 |
| Bosch | 69102 |
| CARTER FUEL PUMPS | P74528S |
| Carquest | HS219627 |
| Carter | P74122, P74123, P74528S |
| DENSO Auto Parts | 951-0016 |
| DORMAN | 692-038 |
| EVO Driveline | AFS0038S, AFS0980P, RE0038S, RE0980P |
| Ford | E9TZ 9H307-B, F1TZ 9H307-D, F57Z 9H307-E, F57Z 9H307-EA |
| GMB | 525-6011 |
| Import Direct | E16013 |
| MasterPro Fuel Pumps | MPA27004 |
| Mazda | ZZM4-13-350, ZZM4-13-350A |
| Motorcraft | PFS-37 |
| N/A | ZZM413350, ZZM413350A, E9TZ9H307B, F1TZ9H307D, F57Z9H307E, F57Z9H307EA, USEP2078S, F1089A, C0005H, 4010012 |
| Precision Fuel | A27004, E16083 |
| Spectra Premium | FG37A, SP1158, SP333H, SP37A1H |
| TruGrade | C5341004 |
DELPHI HP10141 Fits Vehicles
- Mazda B4000 (1994-1997)
- Mazda B3000 (1994-1995)
- Mazda B2300 (1994-1997)
- Ford Ranger (1989-1997)
