(888) 312-8812 Login SignupMONROE 5682 OESpectrum Suspension Shock Absorber
Tap to view 5 more
MSRP: $95.72
$5699
Save $38.73
Limited availability at this price!
In Stock
Get it by Wednesday, Feb 18
MONROE 5682 Part Description
Manufacturer
Product Description
OESpectrum Suspension Shock Absorber
Features & Benefits
- REDUCED NOISE, VIBRATION AND HARSHNESS -- Twin Technology™ Active Control System delivers exceptional control under most driving conditions while isolating impact-related noise, vibration and harshness
- EXCEPTIONAL HANDLING -- Full displaced valving, tuned specifically to each vehicle, adjusts to road extremes while the larger bore provides more efficient damping control to provide consistency and a smooth ride
- CONTROL AND DURABILITY -- PTFE-banded piston provides consistent sealing between piston and pressure tube for better control and increased durability
- CONSISTENT RIDE -- OE all-weather fluid contains special additives to assist with extreme temperatures and help reduce oil breakdown
- IMPROVES PERFORMANCE -- Nitrogen gas-charge maintains tire-to-road contact for improved ride and handling by reducing aeration and shock fade
- BUILT TO LAST -- Self-lubricating fluid seal retains gas and reduces excessive friction against the piston rod to help reduce premature wear
- BUY WITH CONFIDENCE -- Comes with Monroe’s Limited Lifetime Warranty and exclusive Feel the Difference™ Guarantee
- BUY WITH CONFIDENCE -- Comes with Monroe's Limited Lifetime Warranty and exclusive Feel the DifferenceTM Guarantee
MONROE 5682 Specifications
Product Attributes
| Lower Mount Code | LS6 |
| Upper Mount Code | S4 |
| Dust Shield Included | Yes |
| Includes Bump Stop | Yes |
| Internal Rebound Bumper | Yes |
| Hydraulic Lockout | No |
| Part Description | Shock Absorber |
| Compressed Length | 18.94 IN |
| Extended Length | 23.62 in |
| Gas Charged | Yes |
| Lower Mount Type | Loop Bushing and Sleeve Mount - 10MM Sleeve ID X 1.9/16" Sleeve OAL |
| Parts Pack(s) | P01136 |
| Travel Length | 4.68 in |
| Upper Mount Type | Stem Mount - 2.3/8" Stem Length X 3/8"-16 Thread Pitch |
| Compressed Length | 481.1 MM |
| Extended Length | 599.9 MM |
| Travel Length | 118.9 MM |
| Shock Absorber Rod End Measuring Point | Base of Stem |
| Shock Absorber Body End Measuring Point | Center of Loop |
| Lower Mount Type | Loop (Eyelet) Bushing and Sleeve |
| Lower Mount Code | LS6 |
| Upper Mount Code | S4 |
| Mounting Hardware Included | Yes |
| Grade Type | Premium |
| Active or Passive Suspension | Passive |
| Adjustable Compression | No |
| Adjustable Rebound | No |
| Adjustable Ride Height | No |
Additional Information
| MSDS Sheet Number | 01170 |
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708803000 |
| Harmonized Tariff Code (Schedule B) | 8708800050 |
| Harmonized Tariff Code (HTS) | 8708801600 |
| UPC | 00048598138866 |
| VMRS Code | 016008003 |
| UNSPSC | 25172011 |
MONROE 5682 Cross References
| Brand | Part Number |
|---|---|
| 5682ST, GB5Z78045A76DA | |
| Bilstein | 19213828 |
| Duralast | TS3231092B |
| FCS | 346090 |
| FCS AUTO PARTS | 346090 |
| GABRIEL | G51905, G511037 |
| Honda | 51611SZTA01, 51611SZTA11, 51611SZTA51, 51611SZTA61, 51611SZTA71, 51611TK6A02, 51611TK6A11, 51611TK6A50, 51611TK6A51, 51611TK6A71, 51611TX9A03, 51621SZTA01, 51621SZTA11, 51621SZTA51, 51621SZTA61, 51621SZTA71, 51621TK6A02, 51621TK6A11, 51621TK6A50, 51621TK6A51, 51621TK6A71, 51621TX9A03, 52610SZTA11, 52610SZTA110M1, 52610SZTA51, 52610SZTA71, 52610SZTA82, 52610TK6A03, 52610TK6A13, 52610TK6A50, 52610TK6A51, 52610TK6A71, 52610TX9A03 |
| KYB | 348019, 348060, 348016 |
| KYB AMERICA LLC. | 348016 |
| MasterPro Shocks and Struts | HN110 |
| Monroe Shocks & Struts | 210095 |
| NAPA Shocks | 5682, 94388, NS5682 |
| OEM | 52610TK6A51, 52610TK6A03, 52610SZTA82, 52610SZTA51, 52610SZTA11, 52610TK6A13, 52610SZTA71, 52610TK6A71, 52610TX9A03, 52610TK6A50, 52610SZTA110M1 |
| SENSEN | 3213-0269 |
| Sensen | 32130269 |
| Top Quality | 785682 |
| UNITY AUTOMOTIVE | 2-253300-001, 4-11311-253300-001, 253300 |
MONROE 5682 Fits Vehicles
- Honda City (2010-2014)
- Honda CR-Z (2011-2015)
- Honda Fit (2009-2014)
