MSRP Pricing shown.
Out of Stock
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
| Overall Outside Diameter | 5.434 in |
| Overall Outside Diameter | 138 mm |
| Crank Bore | 1.044 in |
| Crank Bore | 26.51 mm |
| Overall Width | 1.544 in |
| Overall Width | 39.20 mm |
| Nose Outside Diameter | 1.457 in |
| Nose Outside Diameter | 37 mm |
| Ring Width | 1.048 in |
| Ring Width | 26.60 mm |
| Crank Trigger/Exciter Plate | Yes |
| Woodruff Key Included | No |
| Hardware Included | No |
| Counterweight Balance | Neutral, no counterweight |
| Timing Marks | No |
| Installation Instructions Included | No |
| Number of Integrated Pulleys | 1 |
| Pulley 1 Type | Serpentine |
| Pulley 1 Number Of Grooves | 6 mm |
| Outer Ring Material | Cast Iron |
| Country of Origin (Primary) | AU |
| Harmonized Tariff Code (Schedule B) | 8483509080 |
| UPC | 09317010011645 |
| Brand | Part Number |
|---|---|
| ATP | NA |
| DORMAN | 594-436 |
| NAPA | 6005173 |
| PIONEER | NA |
