WEATHERHEAD H00904-25R Part Description
Manufacturer
| Abrasion Resistance | Standard |
| Application | Air and multi purpose. |
| Bend Radius Min | 2.5 inch |
| Burst Pressure | 1600 psi |
| Color | Black |
| Conductivity | Conductive |
| Construction | 1 Ply Braid |
| Cover Material | Synthetic Rubber |
| Dash Size | -4 |
| Factory Crimp | Yes |
| InsIDe Diameter | 0.25 inch |
| Lay Line Style | Ink Jet |
| OutsIDe Diameter | 0.53 inch |
| Package Form | Reel |
| Qualified Hose Fittings | E, 009 H Series |
| Reinforcement Material | Textile |
| Tube Material | Synthetic Rubber |
| Working Pressure | 400 psi |
| Working Temperature Max | 212 degree Fahrenheit |
| Working Temperature Min | -40 degree Fahrenheit |
Features & Benefits
- Maximum durability under harsh operating conditions
- Robust construction able to withstand highest pressures
- System engineered to extend hose assembly life
WEATHERHEAD H00904-25R Customer Reviews
No reviews yet
Be the first to review this product!
WEATHERHEAD H00904-25R Manufacturer Information
Officially acquired by Eaton in 2002, Weatherhead® is one of the industry’s biggest suppliers of hydraulic hose, hose ends, tube fittings, couplings, assembly equipment, and support accessories. Weatherhead crafts top-products that are widely used in mining, agriculture, construction, truck, and bus applications. Eaton delivers Weatherhead thermoplastic tubing in different sizes—from 1/8 to 1 inch—designed for use in air tools, robotics, beverage dispensing as well as air and water supply. Driven by the company’s goal to offer unique solutions to a wide range of markets that enable businesses to be at the forefront of change, Weatherhead remains the truck industry’s leading source of premium-quality hoses, fittings, and adapters for your fleet’s hose and fittings needs
