WEATHERHEAD part description

End Size 12
End Type Tube-O
Hose Family Refrigerant
Hose Size 12
Material Other/mixed
Product Line Aeroquip
Shape 90
Style Permanent
A in 4.74
Application Common to air conditioning systems, both in vehicle and commercial applications.
Connection Size 12
D in 3.16
Description 90 Elbow - Female O-ring (short pilot)
Family E-Z Clip Systems
H in 2.56
Hex "1" 1.25
Hex Size 1.25
Hose Cut-Off Factor D 3.16
Plating Zinc
Product Type Fitting
Series Hose Ends
Thread T 1 1/16-14
Type E-Z Clip

Features & Benefits

  • E-Z to Use – and virtually leak free
  • Simplicity of Design, Easy to Use
  • Designed for use with Eaton GH134
  • Sizes 4, 6, 8, 10, 12 and 16
  • Currently available with GH001 in sizes 6, 8 and 10
  • The most widely used field assembly A/C fitting in use in North America!

Officially acquired by Eaton in 2002, Weatherhead® is one of the industry’s biggest suppliers of hydraulic hose, hose ends, tube fittings, couplings, assembly equipment, and support accessories. Weatherhead crafts top-products that are widely used in mining, agriculture, construction, truck, and bus applications. Eaton delivers Weatherhead thermoplastic tubing in different sizes—from 1/8 to 1 inch—designed for use in air tools, robotics, beverage dispensing as well as air and water supply. Driven by the company’s goal to offer unique solutions to a wide range of markets that enable businesses to be at the forefront of change, Weatherhead remains the truck industry’s leading source of premium-quality hoses, fittings, and adapters for your fleet’s hose and fittings needs
