CENTRIC 12362028 Part Description
Manufacturer
Product Description
C-Tek Standard Brake Drum
Features & Benefits
- Non-Directional Finishes. Machined non-friction surfaces. Widest application coverage in the aftermarket
- For best operation and ultimate strength
- OE-Matched Fit, Form, and Function
- 100% Mill Balanced
- For vibration free performance
- Meets SAE Standard for Tensile Strength
- For maximum service life and structural integrity
CENTRIC 12362028 Specifications
Product Attributes
| Weight [cntrc] Kgs | 7.045 |
| Weight [cntrc] Lbs | 15.500 |
| Mounting Type [cntrc] | Floating |
| Bolt Circle Diameter [cntrc] Mm | 127.000 |
| Bolt Circle Diameter [cntrc] In | 5.000 |
| Hub Hole / Register [cntrc] Mm | 77.978 |
| Hub Hole / Register [cntrc] In | 3.070 |
| Height [cntrc] Mm | 80.264 |
| Height [cntrc] In | 3.160 |
| Friction Surface Width [cntrc] Mm | 63.500 |
| Friction Surface Width [cntrc] In | 2.500 |
| Product Grade [cntrc] | Standard |
| Maximum Brake Diameter (Discard) | 243.600 MM |
| Maximum Brake Diameter (Discard) | 9.590 IN |
| Bolt Hole Quantity | 5 |
| Outside Diameter | 304.038 MM |
| Outside Diameter | 11.970 IN |
| Outer Cooling Fins | Yes |
| Mounting Hole Diameter | 13.462 MM |
| Mounting Hole Diameter | 0.530 IN |
| Nominal Drum Diameter | 241.000 MM |
| Nominal Drum Diameter | 9.488 IN |
Additional Information
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| UPC | 00805890052463 |
CENTRIC 12362028 Cross References
| Brand | Part Number |
|---|---|
| N/A | 52-125067, 52125067, BD125067, 8981, BD8981, 123.62028, 8981G, 18017179, 140484, PDR0484, 201811, 440-1630, 4401630, 6401630, 733, AD8228, AD8228E, D9354, 87465, X21715, 23090, BD1546, 2565, 2565R, 102565, 2565DGS, 78836028, 8836028, 78-36028, 7836028, 68165, 177349, 36547022 |
| PRONTO | BD8981 |
| RAYBESTOS | 2565, 2565R |
| WAGNER | BD125067 |
CENTRIC 12362028 Fits Vehicles
- Chevrolet Commercial Chassis (1991-1994)
- Chevrolet Caprice (1991-1996)
