(888) 312-8812 Login SignupCENTRIC 122.66000 Centric Premium Brake Drum
Tap to view 4 more
$8449
Limited availability at this price!
In Stock
Get it by Friday, Jul 17
CENTRIC 122.66000 Part Description
Manufacturer
Product Description
Centric Premium Brake Drum
Features & Benefits
- OE style castings ensure superior performance and extended service life. Machined finishes provide cleaner appearance through wheels. Precision machined friction surfaces ensure smooth operation and reduced noise
- For best operation and ultimate strength
- OE-Matched Fit, Form, and Function
- 100% Mill Balanced
- For vibration free performance
- Black Painted Exterior
- For corrosion resistance
CENTRIC 122.66000 Specifications
Product Attributes
| Weight [cntrc] Kgs | 6.818 |
| Weight [cntrc] Lbs | 15.000 |
| Mounting Type [cntrc] | Floating |
| Bolt Circle Diameter [cntrc] Mm | 139.700 |
| Bolt Circle Diameter [cntrc] In | 5.500 |
| Hub Hole / Register [cntrc] Mm | 90.424 |
| Hub Hole / Register [cntrc] In | 3.560 |
| Height [cntrc] Mm | 74.930 |
| Height [cntrc] In | 2.950 |
| Friction Surface Width [cntrc] Mm | 62.230 |
| Friction Surface Width [cntrc] In | 2.450 |
| Product Grade [cntrc] | Premium |
| Maximum Brake Diameter (Discard) | 281.700 MM |
| Maximum Brake Diameter (Discard) | 11.090 IN |
| Bolt Hole Quantity | 6 |
| Outside Diameter | 314.452 MM |
| Outside Diameter | 12.380 IN |
| Outer Cooling Fins | No |
| Mounting Hole Diameter | 11.430 MM |
| Mounting Hole Diameter | 0.450 IN |
| Nominal Drum Diameter | 279.000 MM |
| Nominal Drum Diameter | 10.984 IN |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00805890045694 |
CENTRIC 122.66000 Cross References
| Brand | Part Number |
|---|---|
| N/A | BD60002, E127-71-005, 8106, 8106G, 112005, 15682511, 2352870, 2352876, 3830002, 3846271, 2446271, 2416065, 3756992, 368008, 368009, 18039667, 19171714, 3696266, 140023, 440-1071, 4401071, 6401071, 801, AD8600, D2005, E12308, E12771005, 3840940, 87034, X21174, 23059, BD1034, 8844000, 68145, 36547032, 1777 |
| RAYBESTOS | 2005, 2005R |
| Raybestos Brakes | 2005, 2005R |
| WAGNER | BD60002 |
CENTRIC 122.66000 Fits Vehicles
- GMC 1000 (1966)
- GMC K1000 (1966)
- Chevrolet 3B (1959)
- Chevrolet Truck (1955-1958)
- GMC 100 (1951-1957)
- Chevrolet C10 Panel (1961-1967)
- GMC K1000 Pickup (1966)
- GMC PB1500 Series (1963-1965)
- GMC Suburban (1961-1965)
- GMC PB1000 Series (1961-1966)
- GMC P15/P1500 Van (1967-1970)
- GMC K15/K1500 Suburban (1968-1970)
- GMC Jimmy (1970)
- GMC G25/G2500 Van (1967-1970)
- GMC C15/C1500 Suburban (1968-1970)
- GMC C15/C1500 Pickup (1967-1970)
- GMC 1000 Series (1961-1965)
- Chevrolet Suburban (1960-1966)
- Chevrolet P10 Van (1967-1970)
- Chevrolet P10 Series (1960-1967)
- Chevrolet K10 Suburban (1968-1970)
- Chevrolet K10 Pickup (1961-1970)
- Chevrolet G20 Van (1967-1970)
- Chevrolet C10 Suburban (1967-1970)
- Chevrolet C10 Pickup (1960-1970)
- Chevrolet Blazer (1969-1970)
