(888) 312-8812 Login SignupCENTRIC 120.6504 Premium Brake Rotor
Tap to view 4 more
$164.85
MSRP Pricing shown.
Out of Stock
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
CENTRIC 120.6504 Part Description
Manufacturer
Product Description
Premium Brake Rotor
Application Summary
2003 - 2003 Ford E-150, 2003 - 2003 Ford E-150 Club Wagon, 1994 - 2002 Ford E-150 Econoline, 1994 - 2002 Ford E-150 Econoline Club Wagon, 1994 - 1996 Ford F-150
Features & Benefits
- Symmetric vane; split-core castings for uniform heat distribution. Black E-Coat anti-corrosive coating protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life
Premium rotor; rotors; Centric; brake rotor; break; brake disc; disc brake
CENTRIC 120.6504 Specifications
Product Attributes
| Discard Thickness | 0.963 IN |
| Discard Thickness | 24.45 MM |
| Nominal Thickness | 1.024 IN |
| Nominal Thickness | 26.00 MM |
| Hat Finish | Coated |
| Stud Thread Diameter | 0.500 IN |
| Outside Diameter | 11.709 IN |
| Outside Diameter | 297.40 MM |
| ABS Tone Ring Included | Yes |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Bolt Thread Pitch | 20.000 IN |
| Center Hole Diameter | 3.402 IN |
| Center Hole Diameter | 86.40 MM |
| Mounting Bolt Hole Circle Diameter | 5.500 IN |
| Mounting Bolt Hole Circle Diameter | 139.70 MM |
| Stud/Lug Hole Quantity | 5 |
| Disc Mounting [cntrc] | Hub & Rotor |
| Height | 5.260 |
| Hub Hole/Whl Reg [cntrc] | 86.4 MM |
| Inner Bearing # [cntrc] | 410.91013 |
| Inner Seal # [cntrc] | 417.650 |
| Misc Holes [cntrc] | 5 |
| Outer Bearing # [cntrc] | 410.91012 |
| Vane Style [cntrc] | Straight |
| Weight [cntrc] | 12.050 KG |
| Weight [cntrc] | 26.500 LB |
| Disc Mounting | Hub & Rotor |
| Hub Hole Diameter | 86.4 MM |
| Inner Bearing | 410.91013 |
| Inner Seal | 417.650 |
| Misc Holes | 5 |
| Outer Bearing | 410.91012 |
| Vane Style | Straight |
| Weight | 12.050 KG |
| Weight | 26.500 LB |
Additional Information
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| UPC | 00805890043409 |
CENTRIC 120.6504 Cross References
CENTRIC 120.6504 Fits Vehicles
- Ford E-150 Econoline Club Wagon (1994-2002)
- Ford E-150 Club Wagon (2003)
- Ford E-150 (2003)
- Ford E-150 Econoline (1994-2002)
