(888) 312-8812 Login SignupCENTRIC 120.6201 Centric Premium Brake Rotor
Tap to view 4 more
No Stock Available
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
CENTRIC 120.6201 Part Description
Manufacturer
Product Description
Centric Premium Brake Rotor
Application Summary
Chevrolet Corvette 1982-1963
Features & Benefits
- Symmetric vane; split-core castings for uniform heat distribution. Black E-Coat anti-corrosive coating protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life
Premium rotor; rotors; Centric; brake rotor; break; brake disc; disc brake
CENTRIC 120.6201 Specifications
Product Attributes
| Discard Thickness | 30.860 MM |
| Nominal Thickness | 1.250 IN |
| Hat Finish | Coated |
| Overall Height | 3.079 IN |
| Outside Diameter | 298.200 MM |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Bearings Included | No |
| Center Hole Diameter | 71.500 MM |
| Mounting Bolt Hole Circle Diameter | 120.700 MM |
| Stud/Lug Hole Quantity | 5 |
| Stud/Lug Hole Diameter | 0.457 IN |
| California Proposition 65 Text [basic] | WARNING: Cancer and Reproductive Harm |
| Disc Mounting [cntrc] | Floating |
| Misc Holes [cntrc] | 0 |
| Vane Style [cntrc] | Straight |
| Weight [cntrc] Kgs | 9.090 |
| Weight [cntrc] Lbs | 20.000 |
| Nominal Thickness | 31.750 MM |
| Overall Height | 78.200 MM |
| Center Hole Diameter | 2.815 IN |
| Disc Mounting | Floating |
| Misc Holes | 0 |
| Vane Style | Straight |
| Weight | 9.090 |
Additional Information
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| UPC | 00805890042471 |
CENTRIC 120.6201 Part Interchanges
| Brand | Part Number |
|---|---|
| Raybestos Brakes | 5500, 5500R |
CENTRIC 120.6201 Fits Vehicles
- Chevrolet Corvette (1963-1982)
CENTRIC 120.6201 Cross References
We have 2 alternatives for the 120.6201 by CENTRIC:
