(888) 312-8812 Login SignupSTEMCO 309-0973 Wheel Seal - Guardian HP Seal
MSRP: $152.01
$7899
Save $73.02
Limited availability at this price!
In Stock
Get it by Wednesday, Jul 8
STEMCO 309-0973 Part Description
Manufacturer
Product Description
GUARDIAN HP SEAL
Application Summary
GMC F-120 1985 and Up
Features & Benefits
- Polymer seal construction resists heat generated during sustained braking conditions
- Stationary internal running surface protects the spindle from direct seal contact
- Maintains sealing performance even on spindles with minor surface imperfections
- One-piece unitized design helps reduce installation errors during drive-on setup
- Blocks moisture road salt and debris from entering the wheel end assembly
Stemco Guardian HP Wheel Seal
Seal your wheel ends with confidence using the Stemco Guardian HP Wheel Seal. This seal is built with a unitized sub-assembly that remains stationary on the spindle, allowing the sealing lip to run against a precision-machined internal surface rather than directly on the axle. By separating the sealing interface from the spindle, this design helps reduce wear at the axle shoulder over time. The Stemco 309-0973 uses a high-temperature polymer construction that stands up to the heat generated during heavy braking and downhill operation. Its one-piece, drive-on design simplifies installation and reduces the risk of seal misalignment or cocking during hub assembly, helping promote consistent sealing performance once the trailer is back in service.
STEMCO 309-0973 Specifications
Product Attributes
| Width | 0.91 IN |
| Seal Type | C7 |
| Bore Diameter | 6 .310 IN |
| INNER BEARING CONE | 594A |
| INNER BEARING CUP | 592A |
| INSTALL HANDLE/BODY | 555-0001 |
| OUTER BEARING CONE | 575 |
| OUTER BEARING CUP | 572 |
| SHOULDER OUTER DIAMETER | 4 .767 IN |
| SPINDLE SHOULDER OUTER DIAMETER | 4 .767 IN |
| TOOL HEAD | 555-5071 |
| UNIVERSAL AXLE TOOL HEAD | 555-5076 |
| Bore Diameter | 6.31 |
| SHOULDER OUTER DIAMETER | 4.767 |
| SPINDLE SHOULDER OUTER DIAMETER | 4.767 |
Additional Information
| Harmonized Tariff Code (HTS) | 4016931050 |
| UPC | 00703832130036 |
| VMRS Code | 018002028 |
STEMCO 309-0973 Cross References
| Brand | Part Number |
|---|---|
| AMSTED SEALS AND FORMING | 70598T |
| BOSS SEALS | B43752 |
| CHICAGO RAWHIDE | 43751, 43753 |
| CHICAGO RAWHIDE CLASSIC | 43752 |
| CHICAGO RAWHIDE PLUSXL | 43754 |
| DANA | 504861 |
| Ford | D5HZ1175A, D7HZ1175D, E1HT1175BA, E1HZ1175A, E1HZ1175B, E2HZ1175A, E2HZ1177A, E4HT1175AA, E4HZ1175B, E5HT1175GA, E8HS1175BA, E8HS1175CA, F2HZ1175C, F4HS1175BA |
| Freightliner | 6819970546 |
| GMC | 027074962, 027125816, 15550869, 15557677, 15679880, 15982869, 2317614, 940010019, 940010022, 940010028, 940010030, 940010034, 940010040 |
| GMC/VOLVO | 698768 |
| MECHANEX/BARRIER | 749400P, HS43753 |
| MERITOR | A1205N898 |
| Mack | 32QJ127A, 32QJ267, 32QJ29316, 364SZ202, 88AX420, 88AX461 |
| Meritor | A1205J2194, A1205L2352, A1205Q2487, A1205R2410, A1205T696, A1205U1061, A1205U2101, A1205V2180, A1205V2492, A1805V542 |
| NATIONAL | 370037A, 370338A |
| NATIONAL SEALS | 370003A, 380003A |
| NAVISTAR | ZCP3090973, 414467C91 |
| NOK | 853, 304, 861, 88319, UZ0304E0 |
| National | 370003A, 370034A, 380003A, 5481, 6872S, 9015S |
| Navistar | 1615305C1, 1680802C1, 447551C91, 447574C91, 447574C92, 548347C91, 548347C92, 594962C1, 775698C91, 974526R91, 983570R1 |
| OEM | 1211, 1215, 43875, 45152, 47695, 47696, 49050, 50640 |
| OEM Part Number | 1211, 1215, 43875, 45152, 47695, 47696, 49050, 50640 |
| PIONEER WESTON | 304404 |
| Pioneer Weston | 307408 |
| Stemco | ZCP3090973 |
| TIMKEN | 11L48750, 11P47670, 11S47670, 11S47670T, 11X47676, 11Y47672 |
| TRAILMOBILE | 4131151, 4131160, 4131213 |
| TRISEAL | 70799T, 69699, 70599, 65298U, 65298W, 65156U |
| Trailmobile | 4131170, 4131171, 4131226, 4131231 |
| Triseal Corp | 65056U, 65056W, 65156U, 69799, 70799 |
| VICTOR | SS46847 |
| Volvo | 027074962, 027125816, 15550869, 15557677, 15679880, 15982869, 2317614, 3941956, 940010019, 940010022, 940010028, 940010030, 940010034, 940010040 |
| Western Star | 330783408, 940010022 |
STEMCO 309-0973 Customer Reviews
No reviews yet
Be the first to review this product!
STEMCO 309-0973 Manufacturer Information
STEMCO® is a recognized global leader in manufacturing and supplying a comprehensive line of high-performance systems and components to the commercial vehicle industry. Its wide range of products includes wheel-end components, such as fasteners, hubcaps, bearings, seals, and mileage counters, and brake parts, which include brake drums, brake pads, and adjusters. It also offers suspension products like spring pins, king pin kits, polyurethane suspensions, tie rod assemblies, and mount and blocking components. All these products are made to the highest quality and safety standards to ensure superior performance and maximum durability even when used in the harshest of conditions. STEMCO is ISO-9001:2015 certified.
