MONROE SC2913 Part Description
Manufacturer
Product Description
Magnum Steering Damper
Features & Benefits
- REDUCES VIBRATION -- Ideal for trucks, vans, SUVs, and CUVs, it helps reduce vibrations that travel through the steering system before they get to the driver to improve control and cut down on driver fatigue in all driving conditions
- CONSISTENT PERFORMANCE -- All-weather fluid contains special additives to assist with extreme temperatures and help reduce oil breakdown
- STRONG AND DURABLE -- Sintered iron piston and .50-in. nitrocarburized piston rod for enhanced durability and long service life
- EXCEPTIONAL HANDLING -- Full displaced valving delivers better valving range on both compression and extension cycles for consistent performance
- LONGER SERVICE LIFE -- Self-lubricating fluid seal retains gas without excessive wear or friction
- MOUNTS HORIZONATALLY -- Micro-cellular gas design allows the unit to be mounted horizontally without impacting performance for improved steering control
MONROE SC2913 Specifications
Product Attributes
| Compressed Length | 14.15 IN |
| Extended Length | 23.99 in |
| Shock Absorber Body End Measuring Point | Center of Loop |
| Travel Length | 9.88 in |
| Body Diameter | 1.86 IN |
| Lower Mount Type | Loop Bushing Mount - 5/8" Bushing ID X 1-5/16" Bushing OAL |
| Lower Mount Code | L1 |
| Upper Mount Type | Loop Bushing Mount - 5/8" Bushing ID X 1-5/16" Bushing OAL |
| Upper Mount Code | L1 |
| Dust Shield Included | No |
| Dust Shield Material | N/A |
| Gas Charged | No |
| Parts Pack(s) | P00837,P00576 |
| Shock Absorber Rod End Measuring Point | Center of Loop |
| Part Description | Steering Damper |
| Compressed Length | 359.4 MM |
| Extended Length | 609.3 MM |
| Travel Length | 251 MM |
| Body Diameter | 47.2 MM |
Additional Information
| MSDS Sheet Number | 1164 |
| Country of Origin (Primary) | US |
| Canadian Harmonizing Tariff Code | 8708949900 |
| Harmonized Tariff Code (Schedule B) | 8708947550 |
| Harmonized Tariff Code (HTS) | 8708947550 |
| UPC | 00048598029027 |
| VMRS Code | 015004022 |
| UNSPSC | 25174202 |
MONROE SC2913 Cross References
| Brand | Part Number |
|---|---|
| SC2913MM, MAESC2913 | |
| ACDelco | 509606 |
| BULLDOG HD SHOCKS | HD5113-0016 |
| Bulldog HD | HD51130016 |
| Carquest | SS10325 |
| Chevrolet | 22011982 |
| GMC | 22011982 |
| Gabriel | 6804SE, 14017 |
| General Motors | 22002710, 22046454, 22046814, 220644062, 3196958, 4941313, 4993563 |
| Gold Shock Absorber | 8550024 |
| HALDEX | SC2913 |
| KYB | SS10325, SS10329 |
| KYB AMERICA LLC. | SS10325 |
| MOOG | SSD15, SSD84 |
| MOOG Chassis Products | SSD15, SSD84 |
| Moog Vintage | SSD84, SSD15 |
| NAPA Shocks | SC2913 |
| NAVISTAR | AMSSC2913 |
| Rancho | RS5404 |
MONROE SC2913 Fits Vehicles
- GMC K25/K2500 Suburban (1973-1974)
- GMC K25/K2500 Pickup (1973-1974)
- GMC K15/K1500 Suburban (1973-1974)
- GMC K15/K1500 Pickup (1973-1974)
- Chevrolet K20 Pickup (1973-1974)
- Chevrolet K10 Pickup (1973-1974)
- GMC V3500 (1987-1991)
- GMC V2500 Suburban (1987-1991)
- GMC V2500 (1987)
- GMC V1500 Suburban (1987-1991)
- GMC V1500 (1987)
- GMC P3500 (1985-1999)
- GMC K3500 (1979-1986)
- GMC K35 (1977-1978)
- GMC K2500 Suburban (1979-1986)
- GMC K25 Suburban (1975-1978)
- GMC K2500 (1979-1986)
- GMC K25 (1975-1978)
- GMC K1500 Suburban (1979-1986)
- GMC K15 Suburban (1975-1978)
- GMC K1500 (1979-1986)
- GMC K15 (1975-1978)
- GMC Savana 3500 (1996)
- GMC Jimmy (1973-1991)
- GMC G3500 (1993-1996)
- Chevrolet V3500 (1989-1991)
- Chevrolet V2500 Suburban (1989-1991)
- Chevrolet V30 (1987-1988)
- Chevrolet V20 Suburban (1987-1988)
- Chevrolet V20 (1987)
- Chevrolet V1500 Suburban (1989-1991)
- Chevrolet V10 Suburban (1987-1988)
- Chevrolet V10 (1987)
- Chevrolet P30 (1985-1999)
- Chevrolet K30 (1977-1986)
- Chevrolet K20 Suburban (1973-1986)
- Chevrolet K20 (1975-1986)
- Chevrolet K10 Suburban (1973-1986)
- Chevrolet K10 (1975-1986)
- Chevrolet K5 Blazer (1975-1986)
- Chevrolet Blazer (1973-1974, 1987-1991)
