(888) 312-8812 Login SignupMONROE MA765 Max-Air Air Adjustable Air Shock Absorber Pack of 2
Tap to view 3 more
MSRP: $176.24
$15349
Save $22.75
Limited availability at this price!
In Stock
Get it by Tuesday, Dec 16
MONROE MA765 Part Description
Manufacturer
Product Description
Max-Air Air Adjustable Air Shock Absorber Pack of 2
Features & Benefits
- MAINTAIN RIDE HEIGHT UNDER LOAD -- Air chamber can be inflated or deflated up to 150 PSI to maintain level height with additional weight up to 1,200 lbs. (capacity is limited by suspension, tires and transmission; see owner's manual)
- EASY TO ADJUST -- Special air fitting resists air leakage and ties into factory system (where applicable) or manually inflates with an air compressor; pair with Monroe air shock accessory and shock air hose AK kits (varies by application)
- EXCEPTIONAL HANDLING -- Full-displaced valving on compression and extension cycles for a smooth ride
- BUILT TO LAST -- Hardened and precision ground piston rod for consistent performance, sintered iron piston for enhanced durability and longer service life and lubricated air sleeve reduces friction for smooth operation
- CONSISTENT RIDE -- OE all-weather fluid contains special modifiers to handle extreme temperatures and help reduce friction and ensure smooth rod reaction
MONROE MA765 Specifications
Product Attributes
| Compressed Length | 12.875 IN |
| Extended Length | 20.5 in |
| Travel Length | 7.625 in |
| Lower Mount Code | L1/CP4 |
| Lower Mount Type | L1/CP4 |
| Upper Mount Code | XP12 |
| Upper Mount Type | Cross Pin Mount - Open Ended, 3/8" Hole ID (Both Ends) X 3.3/16" Pin Length (Hole Center to Center) |
| Dust Shield Included | Yes |
| Dust Shield Material | Rubber |
| Includes Bump Stop | Yes |
| Hydraulic Lockout | No |
| Parts Pack(s) | (2) P00072 |
| Part Description | Air Shock Absorber |
| Internal Rebound Bumper | Yes |
| Compressed Length | 327 MM |
| Extended Length | 520.7 MM |
| Travel Length | 193.7 MM |
| Shock Absorber Body End Measuring Point | Center of Loop |
| Shock Absorber Rod End Measuring Point | Center of Cross Pin |
| Lower Mount Type | Loop Bushing and Cantilever Pin Mount - 1/2" Stud Diameter X 1 1/2" Stud Length (Center of Loop to Frame) |
Additional Information
| MSDS Sheet Number | 1164 |
| Country of Origin (Primary) | US |
| Canadian Harmonizing Tariff Code | 8708803000 |
| Harmonized Tariff Code (Schedule B) | 8708801600 |
| Harmonized Tariff Code (HTS) | 8708801600 |
| UPC | 00048598031259 |
| VMRS Code | 016008003 |
| UNSPSC | 25172011 |
MONROE MA765 Part Interchanges
| Brand | Part Number |
|---|---|
| Jeep | 4637102, 4637103, 4637523, 4637525, 4886509AA, 4886509AE, 4897412AA, 4897412AD, 4897412AF, 4897413AA, 4897413AB, 4897413AD, 4897413AF, 4897414AA, 4897414AD, 4897414AE, 52003288, 52087776, 52087777, 52087777AD, 52087777AE, 52087831, 52087948, 52087948AD, 83500312, 83500313, 83500314, 83500315, 83500316, 83500317, 83500326, 83501159, 83501160, 83501161, 83501188, 83502511, 83502512, 83502514, 83502515, 83504211, 83504212 |
| Gabriel | 49226 |
| NAPA Shocks | MA765 |
MONROE MA765 Fits Vehicles
- Jeep Wagoneer (1984-1990)
- Jeep Cherokee (1984-2001)
MONROE MA765 Cross References
We have 3 alternatives for the MA765 by MONROE:
