(888) 312-8812 Login SignupRAYBESTOS 980973 Raybestos Specialty - Street Performance Brake Rotor
$73.55
MSRP Pricing shown.
Out of Stock
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
RAYBESTOS 980973 Part Description
Manufacturer
Product Description
Raybestos Specialty - Street Performance Brake Rotor
Application Summary
2017-2012 Toyota Camry Front, 2018-2011 Lexus ES350 Front, 2018-2012 Toyota Avalon Front, 2018-2013 Lexus ES300h Front
Features & Benefits
- Application Specific Enhanced Iron
- Raybestos® Performance Rotors are made with enhanced iron which suppresses noise and keeps brakes running cool, quiet and vibration free.
- Raybestos(R) Performance Rotors are made with enhanced iron which suppresses noise and keeps brakes running cool, quiet and vibration free.
- Cooling Vanes
- The cooling vanes match OE configurations and provide optimal cooling and reduced fade.
- Application Specific Coating
- Depending on the application, Performance Rotors will have one of the following finishes: Black fusion coating on the rotor hat Grey Fusion 4.0® coating on the entire rotor
- Depending on the application, Performance Rotors will have one of the following finishes: Black fusion coating on the rotor hat Grey Fusion 4.0(R) coating on the entire rotor
- Depending on the application, Performance Rotors will have one of the following finishes:Black fusion coating on the rotor hatGrey Fusion 4.0® coating on the entire rotor
- Black fusion coating on the rotor hat and Grey Fusion 4.0® coating on the rotor inboard surface and cooling vanes
- Black fusion coating on the rotor hat and Grey Fusion 4.0(R) coating on the rotor inboard surface and cooling vanes
- Turned Finish
- Turned finish minimizes noise and improves responsiveness for smoother stops.
- S-Groove Slot
- Depending on the application, some Raybestos® Performance Rotors are designed with a patented S-Groove Slot.
- Depending on the application, some Raybestos(R) Performance Rotors are designed with a patented S-Groove Slot.
RAYBESTOS 980973 Specifications
Product Attributes
| Center Hole Diameter | 2.44 IN |
| Center Hole Diameter | 62 MM |
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
| Directional or Non-Directional Brake Surface | Non-Directional |
| Discard Thickness | 0.984 IN |
| Discard Thickness | 25 MM |
| Harmonize Code | 8708.30.5030 |
| Inside Diameter | 7.449 IN |
| Inside Diameter | 189.2 MM |
| Material | Cast Iron |
| Mounting Bolt Hole Circle Diameter | 4.5 IN |
| Mounting Bolt Hole Circle Diameter | 114.3 MM |
| Mounting Bolt Hole Diameter | 0.566 IN |
| Mounting Bolt Hole Diameter | 14.4 MM |
| Mounting Bolt Hole Quantity | 5 |
| Nominal Thickness | 1.102 IN |
| Nominal Thickness | 28 MM |
| Outside Diameter | 11.654 IN |
| Outside Diameter | 296 MM |
| Overall Height | 1.945 IN |
| Overall Height | 49.4 MM |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Vented |
| Stud/Lug Hole Quantity | 5 |
| Surface Type | Smooth |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708309990 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00887213014846 |
RAYBESTOS 980973 Cross References
| Brand | Part Number |
|---|---|
| ADVANCE AUTO PARTS | BD126407 |
| ADVICS | A6F063 |
| ATE BRAKE PRODUCTS | 428274 |
| AUTOPARTSOURCE | 579615 |
| AutoZone | 44582DL |
| BENDIX | PRT6155 |
| BOSCH | 50011560 |
| BRAKEBEST | 50011560, 980973, 980973R, 980973RGS |
| BrakeBest | 921379RGS |
| CENTRIC | 120.44146 |
| MAGMA PRODUCTS | PSR563107 |
| PROMAX | 14-31609 |
| STANDARD ROTORS AND DRUMS | GP31434 |
| TOYOTA | 4351206150, 4351233140 |
| TopNotch | TN980973GEO |
| UAP | 2031434 |
| WAGNER BRAKE | BD180063 |
| WORLDPARTS | WS1-231609 |
RAYBESTOS 980973 Fits Vehicles
- Lexus ES300h (2013-2018)
- Lexus ES350 (2011-2018)
- Toyota Avalon (2012-2018)
- Toyota Camry (2012-2017)
RAYBESTOS 980973 Customer Reviews
No reviews yet
Be the first to review this product!
RAYBESTOS 980973 Questions & Answers
No questions yet
Be the first to ask a question about this product!
